Frico rd36e23 [10/16] Safety keep the areas around the air intake and exhaust grilles free from possible obstructions during operation the surfaces of the unit are hot the unit must not be fully or partially covered with textiles or similar materials as overheating can result in a ﬁre risk

RD E

Safety

•฀ Keep฀the฀areas฀around฀the฀air฀intake฀

and฀exhaust฀grilles฀free฀from฀possible฀

obstructions!

•฀ During฀operation฀the฀surfaces฀of฀the฀unit฀

are hot!

•฀ The฀unit฀must฀not฀be฀fully฀or฀partially฀

covered with textiles, or similar materials,

as overheating can result in a ﬁre risk!

Type Output

stages

[kW]

Airﬂow

/h]

Sound

level*

[dB(A)]

∆t*

[°C]

Voltage [V]

Amperage [A]

(control)

Voltage [V]

Amperage [A]

(heat)

Length

[mm]

Weight

[kg]

RD18E09 (or RD310E09) 0/6/9 1800 54 15 230V~/2,52A 400V3~/13A 1000 45

(RD315E12) 0/8/12 2500 55 14 230V~/2,52A 400V3~/17,5A 1500 76

(RD320E18) 0/12/18 3600 56 15 230V~/4,20A 400V3~/26A 2000 106

(RD325E18) 0/12/18 4400 57 12 230V~/5,04A 400V3~/26A 2500 138

RD27E15 (or RD410E15) 0/10/15 2700 55 17 230V~/3,36A 400V3~/22A 1000 45

RD365E23 (or RD415E23) 0/15/22,5 3600 56 19 230V~/4,48A 400V3~/32,5A 1500 77

RD54E30 (or RD420E30) 0/20/30 5400 57 17 230V~/6,72A 400V3~/43,5A 2000 107

RD63E36 (or RD425E36) 0/24/36 6300 58 17 230V~/7,84A 400V3~/52A 2500 138

*1) Conditions: Distance to the unit 3 metres. Equivalent absorption area 50 m

*2) ∆t = temperature rise of passing air at maximum heat output and highest airﬂow.

Technical speciﬁcations | Thermozone RD E
