Thermozone AG 4500/5000 A/W
Type Airflow
[m
3
/h]
Sound level*
1
[dB(A)]
Voltage
[V]
Amperage
[A]
Length
[mm]
Weight
[kg]
AG4515A 2650/3980/5300 48/60/67 230V~ 5,6 1500 72
AG4520A 3800/5700/7600 50/62/69 230V~ 8,4 2000 104
AG4525A 5100/7650/10200 5264//71 230V~ 11,2 2500 129
AG5010A 2350/3530/4700 48/60/67 230V~ 5,2 1000 60
AG5015A 3550/5330/7100 50/62/69 230V~ 8,1 1500 84
AG5020A 4650/6980/9300 51/63/70 230V~ 10,6 2000 129
AG5025A 5800/8700/11600 52/64/71 230V~ 13,5 2500 141
*1
) Applicable at water temperature 80/60°C, air temperature +15°C.
*2
) ∆t = temperature rise of passing air at low/medium/high airflow.
*3
) Conditions: Distance to the unit: 5 metres. Directional factor: 2. Equivalent absorption area: 200 m².
Protection class AG4500/5000W with water heat: (IP23).
Type Output
stages*
1
[kW]
Airflow
[m
3
/h]
∆t*
2
[°C]
Water
volume
[l]
Sound
level*
3
[dB(A)]
Voltage
[V]
Amperage
[A]
Length
[mm]
Weight
[kg]
AG4515WL 27/37/44 2400/3600/4800 38/33/31 5,6 48/60/67 230V~ 5,2 1500 95
AG4520WL 43/58/71 3500/5250/7000 36/33/30 7, 8 50/62/69 230V~ 7, 8 2000 132
AG4525WL 57/76/92 4700/7050/9400 36/32/29 9,2 51/63/70 230V~ 10,4 2500 160
AG4515WH 21/27/32 2400/3600/4800 26/22/20 3,8 48/60/67 230V~ 5,2 1500 95
AG4520WH 34/44/53 3500/5250/7000 29/25/23 4,8 50/62/69 230V~ 7, 8 2000 132
AG4525WH 45/59/70 4700/7050/9400 29/24/22 6,4 51/63/70 230V~ 10,4 2500 160
AG5010WL 21/27/33 2100/3150/4200 38/34/31 3,3 48/60/67 230V~ 4,8 1000 77
AG5015WL 34/45/54 3250/4880/6500 32/28/26 5,6 50/62/69 230V~ 7, 5 1500 107
AG5020WL 50/67/81 4250/6380/8500 35/31/28 7, 8 51/63/70 230V~ 9,9 2000 157
AG5025WL 62/83/100 5300/7950/10600 35/31/28 9,2 52/64/71 230V~ 12,5 2500 172
AG5010WH 21/27/33 2100/3150/4200 30/26/23 2,4 48/60/67 230V~ 4,8 1000 77
AG5015WH 25/32/38 3250/4880/6500 23/20/18 3,8 50/62/69 230V~ 7, 5 1500 107
AG5020WH 39/50/59 4250/6380/8500 27/24/21 4,8 51/63/70 230V~ 9,9 2000 157
AG5025WH 49/63/75 5300/7950/10600 27/24/21 6,4 52/64/71 230V~ 12,5 2500 172
*1
) Conditions: Distance to the unit: 5 metres. Directional factor: 2. Equivalent absorption area: 200 m².
Protection class AG4500/5000A without heat: (IP23).
Technical specifications | Thermozone AG 4500/5000 A without heat
