16
AC Corinte
Pressure drop water
Water pressure drop over controls and valves
Pressure drop [kPa]
Pressure drop [bar]
Water flow [m³/h]
Water flow [l/s]
The pressure drop is calculated for an average temperature of 70°C (PVV 80/60).
For other water temperatures, the pressure drop is multiplied by the factor K.
Average temp. water °C 40 50 60 70 80 90
K 1,10 1,06 1,03 1,00 0,97 0,93
Water pressure drop over ACC water coil
Water flow [l/s]
Water flow [m³/h]
Pressure drop [kPa]
Pressure drop [bar]
1
2
3
4
5
6
7
8
9
1 ACC15WL
2 ACC10WL
3 ACC15WH
4 ACC10WH
4 ACC20WL
5 ACC25WL
6 ACC20WH
7 ACC30WL
8 ACC25WH
9 ACC30WH
V
V
0,01
0,1
1,0
0,01
0,1
0,7
101,00,1
70
10
1
