Omperator's anual
www.fubag.ru
--2
2. Description
The is a manual pneumatic tool designed for screwing and unscrewing of the rigid threaded
connections.
wrench
Danger:
-
-
-
-
-
-
Do not direct the pneumatic tool or flow of the compressed air at the people, animals or
your own body. Wear protective spectacles in order to avoid small particles of the dust to
get into your eyes together with the flow of the compressed air.
Do not direct the flow of the compressed air at the compressor.
Do not work without any protective footwear. Do not touch the operating compressor with
wet hands and/or feet.
Do not exceed the recommended operating pressure.
Do not fix, disassemble or carry out any other maintenance operations without
disconnecting the tool from the air channel.
Do not use the spare parts of the other manufacturers. Always use only original spare parts.
Caution:
If revealing any faults immediately discontinue the operation.
-
-
When connecting the pneumatic tool to the compressor hose always block the air escape
cock.
Always follow the safety rules when using the compressed air.
3s. Technical pecifications
The manufacturer reserves himself the right to make the manual's content or function
change without any preliminary notification of the users.
tools
MODEL 100102 100107 100108 100109 100110
Tail size, inch 1/2 1/2 1/2 1/2 1/2
Screwed bolt Max diameter, mm 14 12 12 14 16
No load rotation speed, rpm 7000 150 150 7000 7500
Max torque, Nm 312 61 61 312 680
Inlet diameter, inch 1/4 1/4 1/4 1/4 1/4
Total air consumption, l/min 623 538 538 623 765
Average air consumption at work cycle min , l/min 156 135 135 156 192
Operation pressure, bar 6,3 6,3 6,3 6,3 6,3
Weight, kg 2,18 1,12 1,12 2,18 2,42
Air conductive hose diameter recommended, mm 6х8 6х8 6х8 6х8 6х8
MODEL 100111 100112 100121 100122 100126
Tail size, inch 3/4 3/4 1/2 3/4 1/2
Screwed bolt Max diameter, mm 19 32 16 19 12
No load rotation speed, rpm 4800 4500 7500 4800 150
Max torque, Nm 680 1600 680 680 61
Inlet diameter, inch 1/4 1/4 1/4 1/4 1/4
Total air consumption, l/min 934 1048 765 934 538
Average air consumption at work cycle min , l/min 234 262 192 234 135
Operation pressure, bar 6,3 6,3 6,3 6,3 6,3
Weight, kg 3,09 5,89 2,42 3,09 1,12
Air conductive hose diameter recommended, mm 6х8 6х8 6х8 6х8 6х8
