Electric convector

3. DISPOSAL

Detailed information on the recycling can be obtained from representative of the local authority.

4. WALL INSTALLATION

1. Uncover the original packaging and carefully remove device from it.

2. Remove any foam seals on the edges of the device and release it from polyethylene.

3. Determine the location for the convector in compliance with the minimum distance from the

object and the ﬂoor.

4. Mark the height at which you must install the convector and put labels in visible ﬁxing holes.

5. Drill holes in the wall of the required diameter, insert the dowels*, tighten the set screws*.

6. Attach the mounting brackets to the cover of the unit with the mounting screws.

7. Perform installation on the wall convector, setting the screws installed in the wall brackets with

the holes that are installed on the device.

8. Check the installation. Convector should ﬁt snugly against the wall.

* May not be included in delivery set

Installing castors on the convector

1. Remove the two support legs from the packaging of the convector.

2. Turn the unit so that its bottom was in easy access.

3. Attach the support legs to the bottom of the device to the le and right sides so that the

fastening holes align with the holes on the ﬁxture.

4. Tighten the screws in the existing holes.
