12
Technical data
Cordless drill/screwdriver C 12
Motor voltage 12 V
Idle-running speed 1. Speed 0 - 450 rpm
2. Speed 0 - 1500 rpm
Max torque Soft boring (wood) 18 Nm
Hard boring (metal) 30 Nm
Adjustable torque 1. Speed 2 - 7 Nm
2. Speed 0.5 - 2.5 Nm
Chuck capacity 1.5 - 13 mm
Max. drill diameter for wood 25 mm
Max. drill diameter for metal 14 mm
Tool tting in chuck 1/4“
Weight without battery pack 0.96 kg
Charger LC 45
Supply voltage (input) 230 -240 V~
Line frequency 50/60 Hz
Charging voltage (output) 7,2 - 18 V=
Charging current 3 A
Quick charge max. 3 A
Compensation charge pulsating app. 0.06 A
Charging time NiCd 1.3 Ah app. 25 min
NiCd 2.4 Ah app. 50 min
NiMH 3.0 Ah app. 70 min
Battery pack BPS 12 C NiCd BPS 12 S NiCd BPS 12 S NiMH
Order number 493348 492268 491821
Voltage 12 V 12 V 12 V
Capacity 1.3 Ah 2.4 Ah 3.0 Ah
Temp. range for charging 5 - 45 °C 5 - 45 °C 5 - 45 °C
Temperature monitoring u s i n g N T C r e s i s t o r
Weight 0.56 kg 0.73 kg 0.75 kg
The speci ed illustrations can be found at the beginning of the operating instructions.
1 Before starting up, please ob-
serve the following
1.1 Intended use
Cordless drills are suitable for drilling metal,
wood, plastics and similar materials, as well
as tightening and screwing in screws (into
wood, up to a diameter of 6 mm).
The LC 45 battery charger is designed for
recharging the battery pack listed.
The user is liable for damage and in-
jury resulting from incorrect usage!
1.2 Safety instructions
a) General Safety Rules
WARNING! Read all safety warn-
ings and all instructions. Failure to
follow the warnings and instructions
may result in electric shock, re and/or se-
rious injury.
Save all warnings and instructions for
future reference.
The term „power tool“ in the warnings refers
to your mains-operated (corded) power tool
or battery-operated (cordless) power tool.
