19) TPM (Trusted Platform Module Header)

You may connect a TPM (Trusted Platform Module) to this header.

Pin No. Denition Pin No. Denition

1 LCLK 11 LAD0

2 GND 12 GND

3 LFRAME 13 NC

4 No Pin 14 NC

5 LRESET 15 SB3V

6 NC 16 SERIRQ

intheCMOSwhenthecomputeristurnedoff.Replacethebatterywhenthebatteryvoltagedropstoalow

level, or the CMOS values may not be accurate or may be lost.

You may clear the CMOS values by removing the battery:

1. Turn off your computer and unplug the power cord.

2. Gently remove the battery from the battery holder and wait for one minute.

(Or use a metal object like a screwdriver to touch the positive and negative

terminals of the battery holder, making them short for 5 seconds.)

3. Replacethebattery.

4. Plug in the power cord and restart your computer.

• Always turn off your computer and unplug the power cord before replacing the battery.

• Used batteries must be handled in accordance with local environmental regulations.

 UsethisjumpertocleartheBIOScongurationandresettheCMOSvaluestofactorydefaults.Toclear

the CMOS values, use a metal object like a screwdriver to touch the two pins for a few seconds.

• Always turn off your computer and unplug the power cord from the power outlet before clearing

the CMOS values.

• Aftersystemrestart,gotoBIOSSetuptoloadfactorydefaults(selectLoadOptimizedDefaults)or

manuallyconguretheBIOSsettings(refertoChapter2,"BIOSSetup,"forBIOScongurations).

Open: Normal

Short: Clear CMOS Values

- 21 -
