PRIME B350-PLUS specications summary
(continued on the next page)
Package contents
Check your motherboard package for the following items.
Motherboard
ASUS PRIME B350-PLUS motherboard
Cables
2 x Serial ATA 6.0 Gb/s cables
Accessories
1 x I/O shield
1 x M.2 screw package
Application DVD
1 x Support DVD
Documentation
1 x User Manual
If any of the above items is damaged or missing, contact your retailer.
CPU
AM4
socket for AMD Ryzen™ / 7th Generation A-series / Athlon™ processors
Supports CPU up to 8 cores*
* Due to CPU limitation, CPU cores supported vary by processor.
** Refer to www.asus.com for AMD CPU support list.
Chipset AMD B350 chipset
Memory
AMD Ryzen™ processors:
4 x DIMMs, max. 64GB, DDR4 3200(O.C.)/2933(O.C.)/2666/2400/2133 MHz, ECC
and non-ECC, un-buffered memory
AMD 7th Generation A-series / Athlon™ processors:
4 x DIMMs, max. 64GB, DDR4 2400/2133 MHz, non-ECC un-buffered memory
Dual-channel memory architecture
* Refer to www.asus.com for the latest Memory QVL (Qualied Vendors List).
** Hyper DIMM support is subject to the physical characteristics of individual CPUs.
Graphics
Integrated AMD Radeon™ R Series Graphics in the 7th Generation A-series
processor
Multi-VGA output support: HDMI, DVI-D and D-Sub ports
- Supports HDMI 1.4b with maximum resolution of 4096 x 2160 @24Hz / 2560 x
1600 @60Hz
- Supports DVI-D with maximum resolution of 1920 x 1200 @60Hz
- Supports D-Sub with maximum resolution of 1920 x 1200 @60Hz
- Maximum shared memory of 2048 MB
Multi-GPU
support
Supports AMD CrossFireX™ Technology
Expansion
slots
AMD Ryzen™ processors:
1 x PCI Express 3.0/2.0 x16 slot (max. @x16 mode)
AMD 7th Generation A-series / Athlon™ processors:
1 x PCI Express 3.0/2.0 x16 slot (max. @x8 mode)
AMD B350 Chipset:
1 x PCI Express 2.0 x16 slot (max. @ x4 mode)*
2 x PCI Express 2.0 x1 slots
2 x PCI slots
* PCIe x16_2 slot shares bandwidth with the two PCIe x1 slots.
