Parts List for the Wood Copy Attachment CTP 901120
REF NO. PART NO. DESCRIPTION
1 01-2139 COPYING TOOL
2 01-3155 FIXING TOOL COVER
3 00-0606 FIXING SCREW
4 01-3106 COPYING ARBOR
5 00-0303 SCREW OF ROUND-HEAD MACHINE
6 00-1803 SPRING WASHER
9 00-0118 HEX. SOCKET SCREW BOLT
10 00-0615 FIXING SCREW
11 00-1003 SCREW NUT
12 01-3103 FIXING FRONT PLATE
13 01-3158 COPPER PACKING SHEET (SMALL)
13-1 01-3158-1 COPPER PACKING SHEET (BIG)
14 00-0610 FIXING SCREW
15 00-0613 FIXING SCREW
16 01-2131 HINGE WHEEL
18 01-2123 STEEL ROPE
19 00-0002 HEX. SCREW BOLT
20 01-2118 FLEXIBLE SPRING
21 00-1004 HEX. SCREW BOLT
22 01-2141 FEED PANEL
23 01-3101 CUTTING SLIDE SEAT
24 00-0120 HEX. SOCKET BOLT
25 01-3132 CONTROL ROD
26 01-2129 HINGE WIRE BOLT
27 00-0601 FIXING SCREW
28 01-3130 LOCATING PLATE
29 01-3102A FRONT GUIDE RAIL
30 01-3111 LATHE POST
31 01-3152 SHAFT SLEEVE
32 01-3156 GUIDE PLATE
33 00-1802 SPRING WASHER
34 00-0319 SCREW OF ROUND-HEAD MACHINE
35 01-3107 COPYING BLOCK
36 00-0111 HEX. SOCKET SCREW BOLT
37 00-0616 FIXING SCREW
38 01-3153 ANTI-DEVIATION ROD
39 01-3149 COPYING SHAFT
40 00-0201 HEX. SCREW BOLT
41 01-2110 SUPPORT OF LATHE POST
42 00-0001 HEX. SCREW BOLT
42-1 CTP901120-42-1
NUT M6
43 00-0805 TAPPED BOLT
44 01-3120 LEFT SLEEVE
45 01-3102B BACK GUIDE RAIL
