Parts List for the Wood Copy Attachment CTP 901120

REF NO. PART NO. DESCRIPTION

46 01-3160 STEEL TUBE

48 00-0611 FIXING SCREW

49 01-3133 COPYING HAND WHEEL

50 00-3002 C-TYPE SNAP RING

51 01-2135 LATERAL HEAD CENTER

52 01-3105 CENTER POST

53 01-2138 CONTROL SCREW

54 00-1012 HEX. SCREW NUT

55 01-2134 FEED HAND WHEEL

56 01-3157 CLAMPING BOARD

57 01-3159 PACKING SHEET

58 01-3151 PROLONGED SLEEVE

59 01-3136 MODEL SUPPORT

60 00-0304 SCREW OF ROUND-HEAD MACHINE

61 00-1505 FLAT WASHER

62 00-1507 FLAT WASHER

63 00-1804 SPRING WASHER

64 00-0014 HEX. SCREW BOLT

65 00-0015 HEX. SCREW BOLT

68 01-2113 PACKING BLOCK

69 00-0007 HEX. SCREW BOLT

70 01-3125 RIGHT SLEEVE

71 01-3127 FIXING SHAFT

77 01-2122 COPYING CENTER

78 01-2121 CENTER SLEEVE

79 01-2137 CENTER HANDLE

80 01-2126 DRIVING HINGE WHEEL

81 01-2150 BUSH

82 00-6401 ANTI-LOOSE BUSH

83 01-3161 COPYING BLOCK CONNECTING PLATE

84 01-3162 RUBBER POSTER

85 00-1006 SET SCREW

86 00-1005 HEX NUT

87 CTP901120-87 SUPPORT BLOCK
