Set of Characters
Sprinter 150/150M/250M - 1.0.0en
EN
DE
FR
ES
NO
SV
FI
DA
IT
PT
NL
5. Set of Characters
Benchmark Elevation (BM), Design Elevation* (D.Elv)
BM and Design elevation numeric input consists of 0 ~ 9, space,
decimal, Ft in 1/16 inch separator, the "+" and "-" signs.
Point ID* (PtID)
Point ID alphanumeric input consists of a ~ z, 0 ~ 9 and space.
Accepting character in the existing value
If there is no change for any particular character in the existing entry
field, press ENTER key to accept the old entry.
Clearing all the existing entry field
Highlight the first entry field with "SPACE" character and press
ENTER key to clear the entire last input value.
To discard entry
Press ESC key to discard entry and restore old value.
Point ID increment
Point ID will be automatically incremented by 1from the last point ID,
if point ID input field is not updated manually.
6. Operation
Height and Distance measurement (electronic)
Example of an electronic measurement:
)
Always aim at the center of
bar code staff and focus the
staff image for accurate meas-
urement.
6.1 Height and Distance Measurement
Measurement
Standby Mode
Measuring in
progress
Measurement with
height and distance
Step Key Description
1.
Press to switch on the instrument, Leica logo
is displayed follow by the default measure-
ment standby mode.
2.
Aim at staff and focus. Lightly trigger the
measurement key to activate measurement.
3.
Height and distance measurement is
displayed.
: _ _ _ _ _
: _ _ _ _ _
: >>>>
: >>>>
MEAS
: 1.235 m
: 5.68 m
