D 151 (B,25,115) Diode UDZS15(B)
D 381 (A,53,128) Diode RKZ8.2KG(B2)
D 382 (A,58,126) Diode 1SS301
D 383 (A,51,128) Diode 1SS352
D 401 (A,154,108) Diode KP2311E
D 402 (A,153,102) Diode KP2311E
D 581 (A,99,46) Diode 1SS352
D 582 (A,101,46) Diode CRG03
D 601 (A,104,64) Diode RB551V-30
D 602 (A,107,90) Diode RB751S-40
D 651 (A,101,87) Diode 1SS352
D 751 (A,139,46) Diode RKZ8.2KG(B2)
D 851 (A,8,115) Diode RB551V-30
D 861 (B,112,34) Diode CRG03
D 862 (B,112,37) Diode CRG03
D 863 (A,119,47) Diode RB160L-40
D 901 (B,145,42) Diode CRG03
D 902 (A,156,48) Diode RKZ5.6KG(B2)
D 921 (A,126,127) Diode HZU7L(C3)
D 922 (A,113,129) Diode HZU7L(A1)
D 931 (A,87,119) Diode CRG03
D 941 (A,99,129) Diode CRG03
D 942 (A,103,129) Diode CRG03
D 981 (A,126,122) Diode 1SR154-400
D 982 (A,129,122) Diode 1SR154-400
D 1021 (B,32,109) Diode CRG03
D 1022 (B,32,106) Diode CRG03
D 1023 (A,29,95) Diode DB2X41400
D 1061 (B,119,110) Diode RKZ5.1KG(B2)
L 151 (B,35,118) Inductor LCTAW6R8J2520
L 181 (A,67,82) Chip Ferrite Bead DTL1107
L 401 (A,154,105) Chip Coil LCTAWR15J2520
L 402 (A,147,103) Inductor CTF1786
L 403 (A,145,105) Inductor CTF1786
L 404 (A,151,106) Chip Coil LCTAWR39J2520
L 405 (A,144,107) Inductor CTF1389
L 406 (A,136,101) Chip Coil LCTAW4R7J2520
L 407 (A,157,98) Inductor CTF1786
L 408 (A,156,97) Inductor CTF1786
L 409 (A,135,94) Chip Coil LCTAW470J2520
L 415 (A,146,83) Inductor CTF1786
L 416 (A,149,82) Inductor(A) CTF1786
L 443 (A,147,107) Inductor(B,C) LCYB68NJ1005
L 501 (A,78,46) Chip Ferrite Bead DTL1107
L 502 (A,83,42) Inductor(B,C) CTF1786
L 602 (A,94,76) Inductor CTF1786
L 781 (A,83,31) Inductor CTF1389
L 851 (A,9,109) Inductor CTF1660
L 861 (A,115,40) Coil CTH1475
L 911 (B,50,113) Inductor LCTAW6R8J2520
L 921 (A,127,104) Inductor CTF1713
L 981 (A,114,141) Choke Coil 600 uH CTH1432
L 1003 (A,45,46) Inductor(A,B) CTF1389
L 1004 (A,13,35) Inductor(A,B) CTF1389
L 1005 (A,13,33) Inductor(A,B) CTF1786
L 1021 (A,9,95) Choke Coil 33 uH CTH1417
L 1022 (A,26,102) Inductor CTF1793
X 401 (A,156,90) Oscillator 36.48 MHz CSS1805
X 501 (A,56,48) Oscillator 48.000 MHz CSS1760
X 502 (A,74,72) Oscillator 16.93 MHz CSS1794
Circuit Symbol and No. Part No.
X 601 (A,96,79) Oscillator 20.000 MHz CSS1795
P 301 (A,29,119) Poly Switch MINISMDC075F/24-2
P 401 (B,155,113) Surge Protector IMSA-6802-01Y900
BZ601 (A,10,43) Buzzer CPV1062
VA141 (A,38,133) Varistor VR105C5R0AAA
VA142 (A,40,132) Varistor VR105C5R0AAA
VA143 (A,39,131) Varistor(A,B) VR105C5R0AAA
VA144 (A,37,131) Varistor(A,B) VR105C5R0AAA
VA801 (B,104,22) Varistor EZJZ1V270RM
VA802 (B,112,22) Varistor EZJZ1V270RM
VA803 (B,118,22) Varistor EZJZ1V270RM
VA804 (B,116,22) Varistor EZJZ1V270RM
VA805 (B,115,22) Varistor EZJZ1V270RM
VA806 (B,120,22) Varistor EZJZ1V270RM
VA807 (B,121,22) Varistor EZJZ1V270RM
VA808 (A,125,21) Varistor EZJZ1V270RM
VA809 (B,108,22) Diode DZ2S068C
VA810 (B,105,22) Diode DZ2S068C
VA811 (B,107,22) Diode DZ2S068C
VA921 (B,161,136) Varistor EZJZ1V800AM
VA922 (B,166,136) Varistor EZJZ1V800AM
VA1001 (A,45,48) Diode(A,B) DZ2S068C
VA1002 (A,50,45) Diode(A,B) DZ2S068C
VA1003 (A,50,47) Diode(A,B) DZ2S068C
CN701 (A,94,38) Connector VKN1192
CN802 (A,111,4) Connector CKS6288
CN1001 (A,48,34) Connector(A,B) CKS6346
JA141 (A,45,141) Jack(A,B) YKS5035
JA142 (A,45,139) Connector(C) CKS4124
JA301 (A,21,141) Pin Jack YKB5016
JA981 (A,116,141) Plug CKM1586
JA984 (A,66,21) Connector YKS5040
JA1041 (A,163,135) Jack CKN1091
>
Fuse (10 A) YEK5001
RESISTORS
R 121 (A,129,88) RS1/16SS473J
R 122 (A,130,88) RS1/16SS104J
R 123 (A,126,83) RS1/16SS474J
R 124 (A,119,90) RS1/16SS473J
R 125 (A,118,90) RS1/16SS104J
R 126 (A,123,85) RS1/16SS474J
R 141 (B,46,128) RS1/10SR102J
R 142 (B,41,130) RS1/10SR102J
R 143 (A,39,133) (A,B) RS1/16SS0R0J
R 151 (B,20,116) RS1/10SR101J
R 152 (A,30,107) RS1/10SR0R0J
R 161 (A,88,62) RS1/10SR0R0J
R 162 (A,83,86) RS1/10SR0R0J
R 163 (A,84,86) RS1/10SR0R0J
R 191 (A,83,95) RS1/16SS821J
R 192 (A,83,98) RS1/16SS821J
R 201 (A,66,125) RAB4CQ102J
R 202 (A,76,96) RS1/16SS223J
R 203 (A,78,96) RS1/16SS223J
R 204 (A,77,96) RS1/16SS331J
R 255 (B,121,69) RS1/10SR473J
R 260 (B,138,89) RS1/4SA0R0J
R 263 (A,143,79) RS1/4SA0R0J
Circuit Symbol and No. Part No.
