12
77-318 / 77-319
Contents
• Safety
• Product Overview
• Keypad, Modes, and LED
• Batteries and Power
• Set Up
• Operation
• Applications
• Accuracy Check and Calibration
• Specifi cations
User Safety
WARNING:
• Carefully read the Safety Instructions and
Product Manual before using this product.
The person responsible for the instrument must
ensure that all users understand and adhere to
these instructions.
CAUTION:
• While the laser tool is in operation, be careful
not to expose your eyes to the emitting laser
beam (red light source). Exposure to a laser
beam for an extended time may be hazardous
to your eyes.
CAUTION:
• Glasses may be supplied in some of the laser
tool kits. These are NOT certifi ed safety glasses.
These glasses are ONLY used to enhance the
visibility of the beam in brighter environments or
at greater distances from laser source.
Retain all sections of the manual for future reference.
WARNING:
• The following label samples are placed on
your laser tool to inform of the laser class for
your convenience and safety. Please reference
the Product Manual for the specifi cs on a
particular product model.
EN 60825-1
LASER RADIATION - DO NOT
STARE INTO THE BEAM OR VIEW
DIRECTLY WITH
OPTICAL INSTRUMENTS
CLASS 2 LASER PRODUCT
Max Output ≤ 1 mW @ 630 - 670 nm
Product Overview
Figure A - Laser Tool
1. Window for Side Beam Laser (SLP5 only)
2. Lower Base
3. 1/4 - 20 Threaded Mount
4. Window for Up Beam Laser
5. Window for Front Beam Laser
6. Window for Down Beam Laser
7. Key Hole Slot for Hanging
8. Magnetic Mount
9. Keypad
10. Window for Horizontal Beam Laser (SLP5 only)
11. Pendulum / Transport Lock
Figure B - Keypad Confi gurations
Figure C - Laser Tool Battery Location
12. Batteries - 3 x “AA”
13. Battery Cover
Figure D - Laser Tool Bottom
3. 1/4 - 20 Threaded Mount
6. Window for Down Beam Laser
13. Battery Cover
Figure E - Laser Tool on Tripod / Attachment
14. Center Screw Thread
15. Center Screw Knob
