77-318 / 77-319
Figure F - Laser Tool on Key Hole Slot
7. Key Hole Slot for Hanging
16. Screw, nail, or similar object
Figure G - Laser Tool on Magnetic Mount
Figure H - Pendulum / Transport Lock Positions
Figure J - Laser Modes
Figure K - Up / Down Beam Aligned to Lower Base
Figure L - Manual Mode
Figure M - Up and Down Beam Accuracy
Figure N - Level Beam Accuracy (for Single Beam)
Figure P - Level Beam Accuracy (for Multiple Beams)
Figure R - 90° Square Beam Accuracy
Figure S - Level Beam Accuracy (for Horizontal Line)
Figure T - Horizontal Beam Accuracy
Keypad, Modes, and LED
Keypads (See fi gure
B
)
Power ON / OFF / Mode Key
Modes (See fi gure
J
)
Available Modes (SLP3)
• Dots Only
Available Modes (SLP5)
• Dots Only
• Horizontal Line
• Horizontal Line and Dots
• All beams OFF
LEDs (See fi gure
B
)
Power LED - Solid GREEN
• Power is ON
Power LED - Blinking RED
• Low Battery
Power LED - Solid RED
• Battery Needs Recharging
Lock LED - Solid RED
• Pendulum lock is ON
• Self-Levelling is OFF
Lock LED - Blinking RED
• Out of Compensation Range
Batteries and Power
Battery Installation / Removal
(See fi gure
C
)
Laser Tool
• Turn laser tool to bottom. Open battery compartment
cover by pressing and sliding out.
• Install / Remove batteries. Orient batteries correctly
when placing into laser tool.
• Close and lock battery compartment cover by sliding in
until securely closed.
WARNING:
• Pay close attention to the battery holder’s (+)
and (-) markings for proper battery insertion.
Batteries must be of same type and capacity. Do
not use a combination of batteries with different
capacities remaining.
