14
77-318 / 77-319
Set Up
Mounting on Accessories
Tripod / Accessory Mount (See fi gure
E
)
• Position a tripod / accessory in a place where it will not
be easily disturbed and near the central location of the
area to be measured.
• Set up the tripod / accessory as required. Adjust
positioning to be sure tripod head / accessory mounting
base is near horizontal.
• Remove the leg attachment from the laser tool for easier
mounting.
• Mount the laser tool to the tripod / accessory by pushing
up the center screw and tighten.
CAUTION:
• Do not leave the laser tool unattended on an
accessory without fully tightening the center
screw. Failing to do so may lead to the laser tool
falling and sustaining possible damage.
Key Hole Slot (See fi gure
F
)
• Place a nail, screw, or similar object into a vertical
surface.
• Rotate the lower base of the laser tool and fl ip the key
hole slot up.
• Carefully hang the laser tool onto the nail, screw, or
similar object by the key hole slot on the laser tool.
Magnetic Mount (See fi gure
G
)
• Attach the laser tool to any supportive magnetic surface.
• ALWAYS confi rm that the laser tool is securely attached
to the magnetic surface before leaving unattended.
CAUTION:
• Only mount to metallic objects that will not
be easily disturbed and check for adequate
magnetic strength before leaving unattended.
Failing to do so may lead to the laser tool falling
and sustaining possible damage.
NOTE:
• It is best practice to always support laser tool with
one hand when placing or removing laser tool from an
accessory.
• If positioning over a target, partially tighten the center
screw, align laser tool, and then fully tighten.
Operation
NOTE:
• See LED Descriptions for indications during operation.
• Before operating the laser tool always be sure to check the
laser tool for accuracy.
• In Manual Mode, Self-Levelling is OFF. The accuracy of the
beam is not guaranteed to be level.
• Laser tool will indicate when it is out of compensation
range. Reference LED Descriptions. Reposition laser tool
to be closer to level.
• When not in use, please be sure to power OFF the laser
tool and place the pendulum lock in the locked position.
Power
• Press
to turn laser tool ON.
• To turn laser tool OFF, repeatedly press
until the
OFF mode is selected OR press and hold
for ≥ 3
seconds to turn laser tool OFF while in any mode.
Mode
• Press
repeatedly to cycle through the available
modes.
Self-Levelling / Manual Mode
(See Figures
H
and
L
)
• The pendulum lock on the laser tool needs to be
switched to the unlocked position to enable self-
levelling.
• The laser tool can be used with the pendulum lock in
the locked position when it is required to position the
laser tool at various angles to project non-level straight
lines or points.
Applications
Plumb / Point Transfer
• Establish 2 reference points that need to be plumb.
• Align either the down laser beam or the up laser beam to a
