77-318 / 77-319
set reference point.
• The opposing laser beam(s) will be projecting a point which
is plumb.
• Position the desired object until the laser beam is aligned
with the second reference point that needs to be plumb
with the set reference point.
Level / Point Transfer
• Use front laser beam to project level reference point out
to desired object
• Establish 2 reference points that need to be level.
• Align the front beam laser to a set reference point.
• With a tripod or other stationary object, rotate the laser
unit to project the front laser beam to a new location.
• The laser point at the new location will be level with the
fi rst point.
• Position the desired object until aligned with the laser
point.
(SLP5 only):
• Using the horizontal laser beam, establish a horizontal
reference plane.
• Position the desired object(s) until they are aligned with the
horizontal reference plane to ensure object(s) are level.
Manual Mode (See Figures
H
and
L
)
• Disables self-levelling function and allows laser unit to
project a rigid laser beam in any orientation.
Accuracy Check and
Calibration
NOTE:
• The laser tools are sealed and calibrated at the factory to
the accuracies specifi ed.
• It is recommended to perform a calibration check prior to
its fi rst use and then periodically during future use.
• The laser tool should be checked regularly to ensure its
accuracies, especially for precise layouts.
• Transport lock must be in the unlocked position to
allow the laser tool to self-level before checking
the accuracy.
Up and Down Beam Accuracy
(See fi gure
M
)
•
M
1
Place laser unit as shown with laser ON. Measure
distances D
1
and D
2
. Mark points P
1
and P
2
.
•
M
2
Rotate laser unit 180° keeping same distances for D
1
and D
2
. Align downward laser beam with point P
2
. Mark
point P
3
.
•
M
3
Measure distance D
3
between points P
3
and P
1
.
• Calculate the maximum offset distance and compare to D
3
.
• If D
3
is not less than or equal to the calculated
maximum offset distance the tool must be returned to
your Stanley Distributor for calibration.
Maximum Offset Distance (SLP3):
= (D
1
m x 0,8
mm
m
) + (D
2
m x 0,8
mm
m
)
Maximum
= (D
1
ft x 0,0096
in
ft
) + (D
2
ft x 0,0096
in
ft
)
Maximum Offset Distance (SLP5):
= (D
1
m x 0,4
mm
m
) + (D
2
m x 0,8
mm
m
)
Maximum
= (D
1
ft x 0,0048
in
ft
) + (D
2
ft x 0,0096
in
ft
)
Compare : (See fi gure
M
3
)
D
3
≤ Maximum
Example (using SLP3):
• D
1
= 3 m, D
2
= 1 m, D
3
= 1,5 m
• (3 m x 0,8
mm
m
) + (1 m x 0,8
mm
m
) = 3,4 mm
(maximum offset distance)
• 1,5 mm ≤ 3,4 mm (TRUE, tool is within calibration)
