77-318 / 77-319
• If D
2
is not less than or equal to the calculated
maximum offset distance the tool must be returned to
your Stanley Distributor for calibration.
Maximum Offset Distance:
= 0,4
mm
m
x D
1
m
Maximum
= 0,0048
in
ft
x D
1
ft
Compare : (See fi gure
P
4
)
D
2
≤ ± Maximum
Example:
• D
1
= 10 m, D
2
= 3,0 mm
• 0,4
mm
m
x 10 m = 4,0 mm (maximum offset distance)
• 3,0 mm ≤ 4,0 mm (TRUE, tool is within calibration)
90° Square Beam Accuracy
(SLP5 only) - (See fi gure
R
)
•
R
1
Place laser tool as shown with laser ON.
Mark points P
1
, P
2
, P
3
, and P
4
.
•
R
2
Rotate laser tool 90° keeping the down laser beam
aligned with point P
4
and the front laser beam vertically
aligned with point P
2
. Mark point P
5
.
•
R
3
Rotate laser tool 180° keeping the down laser beam
aligned with point P
4
and the front laser beam vertically
aligned with point P
3
. Mark point P
6
.
•
R
4
Measure the horizontal distance between points
P
1
and P
5
to get distance D
2
and points P
1
and P
6
to get
distance D
3
.
• Calculate the maximum offset distance and compare to
D
2
and D
3
.
• If D
2
and D
3
is not less than or equal to the calculated
maximum offset distance the tool must be returned to
your Stanley Distributor for calibration.
Maximum Offset Distance:
= 0,4
mm
m
x D
1
m
Maximum
= 0,005
in
ft
x D
1
ft
Compare : (See fi gure
R
4
)
D
2
and D
3
≤ ± Maximum
Level Beam Accuracy
(Single Beam) - (See fi gure
N
)
•
N
1
Place laser tool as shown with laser ON. Mark point P
1
.
•
N
2
Rotate laser tool 180° and mark point P
2
.
•
N
3
Move laser tool close to wall and mark point P
3
.
•
N
4
Rotate laser tool 180° and mark point P
4
.
•
N
5
Measure the vertical distance between P
1
and P
3
to get
D
3
and the vertical distance between P
2
and P
4
to get D
4
.
• Calculate the maximum offset distance and compare to the
difference of D
3
and D
4
as shown in the equation.
• If the sum is not less than or equal to the calculated
maximum offset distance the tool must be returned to
your Stanley Distributor for calibration.
Maximum Offset Distance:
= 0,2
mm
m
x (D
1
m - (2 x D
2
m))
Maximum
= 0,0024
in
ft
x (D
1
ft - (2 x D
2
ft))
Compare : (See fi gure
N
5
)
D
3
- D
4
≤ ± Maximum
Example:
• D
1
= 10 m, D
2
= 0,5 m
• D
3
= 0,4 mm
• D
4
= - 0,6 mm
• 0,2
mm
m
x (10 m - (2 x 0,5 m) = 1,8 mm (maximum
offset distance)
• (0,4 mm) - (- 0,6 mm) = 1,0 mm
• 1,0 mm ≤ 1,8 mm (TRUE, tool is within calibration)
Level Beam Accuracy
(SLP5 only) - (Multiple Beam) - (See fi gure
P
)
•
P
1
Place laser tool as shown with laser ON.
Mark points P
1
, P
2
, and P
3
.
•
P
2
Rotate laser tool 90° and mark point P
4
.
•
P
3
Rotate laser tool 180° and mark point P
5
.
•
P
4
Measure the vertical distances between the highest
and lowest points of the group to get D
2
.
• Calculate the maximum offset distance and compare to D
2
.
