Features

This tool includes some or all of the following features.

1. Side Handle

2. Switch

3. Electronic impact energy control dial

4. Chisel position index collar

5. Lube oil-injection inlet

6. Tool holder / sleeve

7. Service indicator

Assembly and adjustments

WARNING: To reduce the risk of injury, turn unit

off and disconnect machine from power source

before installing and removing accessories,

before adjusting or changing set-ups or when making

repairs. Be sure the trigger switch is in the OFF position. An

accidental start-up can cause injury.

Inserting and removing SDS-Max accessories (FIG. A1)

This tool uses SDS-Max chisels (refer to the inset in FIG A1

for a cross-section of a chisel shank). We recommend to

use professional accessories only.

1. Clean and grease the chisel shank.

CAUTION: Do not apply lubricant to the

machine.

2. Insert the chisel shank into the bit holder/tool sleeve (6).

Press and turn the chisel slightly until the sleeve snaps

into position.

3. Pull on the chisel to check if it is properly locked. The

hammering function requires the chisel to be able to

move axially several centimetres when locked in the tool

holder.

4. To remove a chisel, pull back the tool holder/ sleeve (6)

and pull the chisel out of the tool holder.

WARNING: Always wear gloves when you

change accessories. The exposed metal parts

on the tool and accessory may become extremly hot during

operation.

Indexing the chisel position (FIG. D)

The chisel can be indexed and locked into 12 different

positions.

1. Insert the chisel as described above.

2. Pull forward and rotate the chisel position collar (4) in the

direction of the arrow until the chisel is in the desired

position.

Setting the electronic impact power control dial (FIG. A)

Turn the dial (3) to the desired level. The higher the number,

the greater the impact energy. With dial settings from «1»

(low) to «6» (full power) the tool is extremely versatile and

adaptable for many different applications. The required

setting is a matter of experience, for example:

• When chiselling soft, brittle materials or when minimum

break-out is required, set the dial to «1» or «2» (low);

• When breaking harder materials, set the dial to «6» (full

power).

Fitting the side handle (FIG. A)

The side handle (1) can be mounted on the front of the

machine to suit both right hand and left hand users.

WARNING: Always operate the machine with

the side handle properly mounted..

1. Unscrew the side handle clamp knob.

2. Adjust the side handle (1) to the desired angle.

3. Slide and rotate the side handle to the desired position.

4. Lock the side handle in place by tightening the clamp

knob.

Operation instructions for use

WARNING:

• Always observe the safety instructions and applicable

regulations.

(Original instructions) ENGLISH
