• Be aware of the location of pipework and wiring.

• Apply a pressure of approx. 20 - 30 kg to the tool.

Excessive force does not speed up chiselling but

decreases tool performance and may shorten tool life.

• Always hold the tool ﬁrmly with both hands and ensure a

secure stance (FIG. C). Always operate the tool with the

side handle properly mounted.

Proper hand position (FIG. C)

Warning: To reduce the risk of serious

personal injury, ALWAYS use proper hand

position as shown.

Warning: To reduce the risk of serious

personal injury, ALWAYS hold securely in

anticipation of a sudden reaction.

Proper hand position requires one hand on the side handle

(1), with the other hand on the main handle.

Switching on and off (FIG. A)

1. To run the tool, press the switch (2) and turn it in 'ON'

position.

2. To stop the tool, turn it in 'OFF' position and release the

switch (2).

Demolition, chiseling and channelling (FIG. A)

1. Select the appropriate chisel, and clean and grease its

shank.

2. Insert the chisel and check whether it is properly locked.

3. Set the desired impact energy level.

4. Fit and adjust the side handle (1) and make sure it is

ﬁrmly tightened.

5. Hold the tool at main handle and side handle (1) and

switch on. The tool now runs in continuous operation.

6. Always switch off the tool when work is ﬁnished and

before unplugging.

Various types of chisels are available as an option. Only

Stanley recommended accessories should be used with this

product.

Warning:

• Do not use this tool to mix or pump easily combustible or

explosive ﬂuids (benzine, alcohol, etc.).

• Do not mix or stir inﬂammable liquids labelled

accordingly.

Accessory maintenance (FIG. B)

Accessory maintenance at the right time guarantees optimal

results in application and a long and efﬁcient accessory life.

Grind the chisels on grinding discs. Refer to FIG B for the

appropriate angles of the following chisels:

Pointed chisel (8)

Flat chisel (9)

Warning: These chisels can be reground only a

limited number of times. If in doubt, contact your

dealer for recommendations.

Warning: Ensure that the cutting edge does not

show discolouration caused by too much

pressure. This may impair the hardnessof the

accessory.

Maintenance

Your Stanley corded/cordless appliance/tool has been

designed to operate over a long period of time with a

minimum of maintenance. To ensure satisfactory operations,

the tool must be maintained and cleaned regularly

• This machine is not user-serviceable. Take the tool to an

authorised Stanley repair agent after approximately 100

hours of use. If problems occur before this time contact

an authorised Stanley repair agent.

Lubrication

• Open the cap of the lube oil-injection inlet(5), check the

lube oil in the gearbox, if the lube oil is dirty or

insufﬁcient, replace or add the adequate amount of lube

oil provided by the company.

Cleaning

Warning: Blow dirt and dust out of the main

housing with dry air as often as dirt is seen

collecting in and around the air vents. Wear

approved eye protection and approved dust mask when

performing this procedure.

ENGLISH (Original instructions)
