ENGLISH

(Original instructions)

Electrical Safety

Your tool is double insulated; therefore no earth

wire is required. Be sure to check that the power

supply corresponds to the voltage on the rating

plate. Corresponds.

• If the supply cord is damaged, it must be replaced by

the manufacturer or an authorised STANLEY Service

Centre in order to avoid a hazard.

Using an Extension Cable

If it is necessary to use an extension cable, please used an

approvedextension cable that ﬁts the tool’s power input

speciﬁcations (please refer to the technical data). The

minimum crosssectional area of the conducting wire is 1.5

sq. mm. Cables should be untangled before reeling up.

Please refer to the following table.

Features (Fig. E)

This tool includes some or all of the following features.

1. Variable speed switch

2. Lock-on button

3. Mode selector

4. Tool clamp

5. Side handle

6. Depth stop

7. Forward/Reverse lever

Assembly

Warning! Before assembly, make sure that the tool is

switched off and unplugged.

Attaching the Side Handle (ﬁg. E)

Warning! When drilling holes in concrete or bricks, please

use the side handle for your safety.

• Turn the grip counterclockwise until you can slide the

side handle onto the front of the tool.

• Rotate the side handle into the desired position.

• Tighten the side handle by turning the grip clockwise.

Warning! When using the tool, remember to install the side

handles properly.

Voltage Amperes Cable rated current (Ampere)

115 0 - 2.0 6 6 6 6 6 10

2.1 - 3.4 6 6 6 6 15 15

3.5 - 5.0 6 6 10 15 20 20

5.1 - 7.0 10 10 15 20 20 25

7.1 - 12.0 15 15 20 25 25 -

12.1 - 20.0 20 20 25 - - -

230 0 - 2.0 6 6 6 6 6 6

2.1 - 3.4 6 6 6 6 6 6

3.5 - 5.0 6 6 6 6 10 15

5.1 - 7.0 10 10 10 10 15 15

7.1 - 12.0 15 15 15 15 20 20

12.1 - 20.0 20 20 20 20 25 -

Cable cross-sectional area (mm

) Cable rated current (Ampere)

0.75 6

1.00 10

1.50 15

2.50 20

4.00 25

Cable length (m)

7.5 15 25 30 45 60

Read

Instructions

Manual

Use Eye

Protection

Use Ear

Protection

V ........ Volts

A ........ Amperes

Hz ....... Hertz

W ........ Watts

min ..... minutes

..... Alternating

Current

..... Direct

Current

....... No-Load

Speed

...... Class II

Construction

.... Earthing

Terminal

.... Safety Alert

Symbol

.../min.. Revolutions

or Recipro-

cation per

minute

Labels on tool

The label on your tool may include the following symbols

along with the date code:

Position of date barcode

The Date Code, which also includes the year of

manufacture, is printed into the housing.

Example:

2014 XX JN

Year of manufacturing
