ENGLISH

(Original instructions)

Fitting an accessory (ﬁg.A)

• Clean and grease the shank (15) of the accessory.

• Insert the accessory bar into the tool clamp(4).

• Push the accessory down and turn it slightly until it ﬁts

into the slots.

• Pull on the accessory to check if it is properly locked.

The hammering and drilling function requires the

accessory to be able to move axially several centimetres

when locked in the tool clamp.

• To remove the accessory, pull back the sleeve (8) and

pull out the accessory from the tool clamp.

Use

Warning! Please operate tool with normal load. Do not

overload.

Warning! Before drilling into walls, ﬂoors or ceilings, check

for the location of wiring and pipes.

Selecting the Operating Mode (ﬁg. B)

The tool can be used in two operating modes. Based on

actual work requirements, the drilling mode selector (3) can

be rotated to the required position.

Hole drilling / Screw driver (Fig. B,F,G,H)

• For drilling in steel, wood and plastics or tighten and loose

screw, set the operating mode selector (3) to the ( )

position. At the same time, it is necessary to use a

suitable drill chuck (13) (optional accessory) to clamp the

attachment rod.

• Insert the drill chuck (13) into the tool chuck (4) according

to the instructions for installing attachments. Turn the

drill chuck to loosen the clamps at the front-end of the

drillclamp, and insert the accessory bar (14) into the

clamps and turn the chuck in the opposite direction. You

may also use the drill chuck key to tighten the clamp.

• For drilling in steel, wood and plastics, set the forward/

reverse lever(7) to the forward position(Fig G). When use

for screw driver function, tighten screws set the forward/

reverse lever (7) to the forward position(Fig G) and loose

screws set the forward/reverse lever (7) to the reverse

position(Fig H).

Hammer drilling (Fig. B)

• For hammer drilling in masonry and concrete, set the

operating mode selector (3) to the position.

• The drill bit has to be placed accurately onto the drill

hole position. After that, pull the switch for optimal

effects. Make sure the tool is in the correct position to

prevent the drill from deviating from the hole.

• When the drill hole is clogged with debris or ﬁne powder,

please don't exert any more pressure. Tool should be put

in free-running state before removing part of the drill bit

from the hole. If repeated a few times, the blockage in

the hole would be cleared, and normal drilling can

resume.

Warning! When the drill bit hits cement or the

steel rebar in the cement, the tool may recoil

dangerously. Please hold the tool tightly in a

balanced and stable position at all times to

prevent it from recoiling dangerously.

Overload coupling device

If the drill bit his caught or hooked, the driving force

transmitted to the drill shaft will be cut off. This would

generate a strong recoil, so it would be necessary to hold the

tool tightly with both hands to remain in a stable position.

Setting the drilling depth (Fig. E)

The depth stop is a convenient feature to ensure uniformity

in drilling depth. Loosen the side handle to adjust the depth

gauge according to the required depth. After that, tighten the

side handle.

• Slacken the side handle (5) by turning the grip

counterclockwise.

• Set the depth stop (6) to the required position. The

maximum drilling depth is equal to the distance between

the tip of the drill bit and the front end of the depth stop.

• Tighten the side handle by turning the grip clockwise.

Switching on and off

Warning! Before plugging in to the power source, make sure

the switch can be ﬂipped freely, and can return to its original

position once released.

• To switch the tool on, press the variable speed switch

(1). The tool speed depends on how far you press the

switch.

• As a general rule, use low speeds for large diameter drill

bits and high speeds for smaller diameter drill bits.

• For continuous operation, press the lock-on button (2)

and elease the variable speed switch.

• To switch the tool off, release the variable speed switch.

To switch the tool off when in continuous operation, press

the variable speed switch once more and release it.

Accessories

The performance of your tool depends on the accessory

used. STANLEY accessories are engineered to high quality

standards and designed to enhance the performance of your

tool. By using these accessories you will get the very best

from your tool.

rom the interior (when ﬁtted).

• Remove the ﬁxed screws (9) on the carbon brush to

brush that meets the speciﬁcations.

may signiﬁcantly increase the .5exposure level over the

but not actually doing the job. his may signiﬁcantly

LWA (sound power) 99.0 dB(A)
