7
ENGLISH
(Original instructions)
Fitting an accessory (fig.A)
• Push the accessory down and turn it slightly until it fits
Before drilling into walls, floors or ceilings, check
Selecting the Operating Mode (fig. B)
• When the drill hole is clogged with debris or fine powder,
the switch can be flipped freely, and can return to its original
Maintenance
Your STANLEY corded/cordless appliance/tool has been
designed to operate over a long period of time with a
minimum of maintenance. To ensure satisfactory operations,
the tool must be maintained and cleaned regularly
Warning! Before performing any maintenance on corded/
cordless power tools:
• Switch off and unplug the appliance/tool.
• Or switch off and remove the battery from the appliance/
tool if the appliance/tool has a separate battery pack.
• Or run the battery down completely if it is integral and
then switch off.
• Unplug the charger before cleaning it. Your charger does
not require any maintenance apart from regular cleaning.
• Regularly clean the ventilation slots in your
appliance/tool/ charger using a soft brush or dry cloth.
• Regularly clean the motor housing using a damp cloth.
Do not use any abrasive or solvent-based cleaner.
• Regularly open the chuck and tap it to remove any dust
rom the interior (when fitted).
Replace the carbon brush (Fig. D)
• Regularly replace and inspect the carbon brush.
Oncecompletely worn out by continuous wear and
tear, it will have to be replaced. Must keep carbon
brush clean and sliding freely within the brush holder.
Both carbon brushes have to be replaced at the
same time.
• Remove the fixed screws (9) on the carbon brush to
remove the carbon brush (10) and brush holder.
• Remove the coil spring supporting the carbon brush
(11) in the brush holder, and insert a new carbon
brush that meets the specifications.
• Set up the brush holder again and return the
supporting coil spring to its original position.
Cleaning
Warning! Blow dirt and dust out of the main
housing with dry air as often as dirt is seen
collecting in and around the air vents. Wear
approved eye protection and approved dust
mask when performing this procedure.
Warning! Never use solvents or other harsh
chemicals for cleaning the non-metallic parts of
the tool. These chemicals may weaken the
material of the parts. Use only mild soap and damp cloth
to clean the tool. Never let any liquid get inside the tool;
never immerse any part of the tool into liquid.
The vibration emission level given in this information
sheet has been measured in accordance with a
standardised test given in EN 60745 and may be used to
compare one tool with another. It may be used for a
preliminary assessment of exposure.
Warning: The declared vibration emission
level represents the main applications of the
tool. However if the tool is used for different
applications, with different accessories or
poorly maintained, the vibration emission may differ. This
may significantly increase the .5exposure level over the
total working period. An estimation of the level of
exposure to vibration should also take into account the
times when the tool is switched off or when it is running
but not actually doing the job. his may significantly
reduce the exposure level over the total working period.
Identify additional safety measures to rotect the operator
from the effects of vibration such as: aintain the tool and
the accessories, keep the hands arm, organisation of
work patterns.
LpA (sound pressure) 88.0 dB(A)
KpA (sound pressure uncertainty) dB(A) 3
LWA (sound power) 99.0 dB(A)
KWA (sound power uncertainty) dB(A) 3
Vibration emission value ah
ah, HD (Hammer Drilling into concrete) = 13.7 m/s²
Uncertainty K = m/s² 1,5
Rotary hammer STHR202
Power input W 620
Voltage V 220-240
Frequency Hz 50/60
No-load speed /min 0-1250
Impact rate BPM 0-3900
Impact energy J 1.34
Modes 2
Max drilling capacity
Concrete mm 20
Steel mm 13
Wood mm 25
Weight kg 2.6
Technical data
