Lenovo ideapad 310-14IAP/ideapad 310-15IAP Hardware Mainte-
nance Manual
94
Screws
Table 9. Parts list—Screws
FRU P/N CRU
ID
ideapad
310-14IAP
ideapad
310-15IAP
ACLU1 Screw D-C/D-KB/
ODD-D-MB-KB/FAN
90205118 N
●●
Screw L Y700-15ACZ Hinge 3 5S10K26863 N
●●
AILZA Screw
MM2D7.4+4.6LK3.5D1T
90203992 N
●●
AILZA Screw M M 3.0D 3.0L K
4.9D
90203986 N
●●
ACLU1 Screw Panel-A/
MB-D/IO BD-D
90205117 N
●●
Screw L300-IBR
2.5D3.5LK5.3D0.5T
5S10K14049 N
●
QIQY5 SCREW
2D3LK4.5DZKNL+CR3+0.4T
90001118 N
●●
ACLU1 Screw Hinge-D 90205119 N
●
