Bork SW-22 [10/12] Functions

Active Subwoofer SW-22

1 «LINE INPUT» Connects the low level input of the subwoofer to the

«PreAmp», «Monitor Output» or «subwoofer Output» of your receiver

or amplifier. In some cases, you will only have a single output jack

for the subwoofer pre-out. To complete the connection you may

utilize a «V» connector. Or simply use one of the input jacks on the

subwoofer input.

2 «POWER» Power LED

3. «PHASE» Allows the user to switch the phasing of the subwoofer.

Listen to the subwoofer in each of the modes (normal & rcverse)

and select the setting which provides the richest, fullest bass.

4. «VOLUME» Allows the user to adjust the output volume of the

subwoofer.

5. «CROSSOVER FREQUENCY» Allows the user to select the upper

limit at which the subwoofer will play it using high (speaker) level

input, set the crossover frequency to l50Hz to provide to smooth

transition between subwooier and small satellite speakers. When

using low levcl(RCA) inputs, we suggest a frequency band between

55Hz and 150Hz, however experimentation will allow you find the

optimum setting for your installation.

6. «HI LEVEL IN» Allows the user to connect the subwoofer via

the high level (speaker) output terminals of your Receiver or

amplifier.

7. «POWER SW» Mams power on/off.

8. «AC INPUT» Power input plug.

9. «FUSE» AC fuse protector.

CONTROLS AMD

FUNCTIONS

OF REAR PANEL
