5. PACKAGE CONTENTS
The package contents are given in Table 2.
Stock number
Version
Water heater assembly with safety valve*
Installation fixtures (screw - dowel pin), set
Sealing gaskets with filter
Instruction manual
Warranty card
Shower nozzle
Wall holder for shower
Hose for shower nozzle
pc.
1
1
1
1
1
1
1
1
1
WHN-4 OS,
WHP-4 OS
shower
+
+
+
+
+
+
+
+
WHN-5 OS,
WHP-5 OS
shower
+
+
+
+
+
+
+
+
Table 2
* May be not included in the set of delivery.
6. WATER HEATER INSTALLATION
Location
1. The water heater can be installed in any place provided that temperature
in the room is not below 0°C.
2. The water heater is installed onto flat wall surface so that water and
splashes cannot get onto its enclosure.
3. During selection of a location for the water heater, it is necessary to
ensure free access to it on the basis of not less than 0.3 m from above, from
below, and sideways. This will ensure the maximum comfort of
maintenance and adjustment of the water heater, when necessary.
4. The water heater shall be installed so that distance from the appliance
bottom to the floor is not more than 1.6 m.
5. Possible installation options of the water heater are given in Fig.2.
www.timberk.com instant water heater
ENGLISH
