2. operation

1 After unpacking the product pull out the shredder bag frame and remove the CD shard tray,

which sits on top of the bag frame. Store this tray on the product as shown and use when you

shred CDs.

2 Lift up the loading door and open oil ap.

3 Remove oil cap and ll up the reservoir using the 60ml bottle of oil provided. Replace the cap.

4 Connect the shredder to mains supply.

5 Check that the on/o switch at the back of the machine is switched to the ‘ON’ position.

6 Press and hold down the Auto button (

) for 5 seconds to start the pump and prime the

system. Only required when the product is used for the rst time.

7 To load the shredder, simply lift the loading door handle to open the loading door and insert

documents. You can open the door further to 90 degrees for easier access if required Load up to

500 sheets at a time into the feed chamber.

Do not ll above the MAX level, this could damage the shredder.

8 The shredder will start the shredding cycle automatically ONLY after closing the loading door.

If there is paper in the Autofeed chamber after rst attempt, open and re-close the paper loading

door a second time.

Attention: If required you can now lock the loading door by entering a 4 digit code (see Locking

the Paper Loading Door section).

9 If you only have up to 9/10 sheets to shred, you can use the manual feed slot, provided the auto

feed chamber is empty.

10 Insert paper to be shredded into the feed area. The shredder will detect the paper and start

automatically.

11 If the shredder is left in auto mode for more than 2 minutes without being used, the shredder will

automatically turn back to sleep mode in order to save power.

12 The shredder will automatically ‘wake up’ from sleep mode when paper is inserted into the

shred mouth or you open the loading door. There is no need to press the Auto button (

3. reverse function

1 Should you wish to reverse paper out whilst shredding, a reverse button (

) has been tted for

your convenience.

2 Reverse the paper out then turn the machine o using the ON/OFF switch at the rear of the

shredder. Remove the paper from the manual feed slot (if being used) or open the loading door,

remove the remaining stack of paper, then pull the jammed paper free of the cutting mechanism.

3 To resume shredding, turn the shredder on using the ON/OFF switch at the rear of the shredder.

Return the switch to the auto position (
