REF NO
F4-PART CODE
DESCRIPTION（
（（
（EN）
））
）
Q'TY
1 F4-04.01.02.00 hexagonal head nut M8 1
2 F4-03.02 plate 1
3 F4-03.01.01 clamp bracket(left) 1
4 F4-03.03 gasket,nylon 2
5 F4-03.02.02 clamp,bracket(right) 1
6 M8*135 hexagonal bolt M6×135 1
7 GB933 M6*10 hexagonal bolt M6×10 2
8 F4-03.05.02.01 1
9 F4-03.05.08.04 torional spring ,locking bail B 1
10 F4-03.05.08.03 torional spring,locking bail A 1
11 GB933 M6*35 hexagonal bolt M6*35 6
12 F4-03.05.04 cover,swivel bracket 1
13 F4-03.05.01 swivel bracket 1
14 GB934 M6 hexagonal nut M6 1
15 GB848 M6 gasket 6 1
16 F4-03.04 pad pipe,bolt 1
17
GB933 M6*120
hexagonal bolt M6*120 1
18 GB933 M6*20 hexagonal bolt M6*20 2
19 F4-03.05.03 binder plate,adjustable bracked 1
20 F4-03.05.02.05 gasket,impair abrasion 2
21 F4-03.05.02.04 torsion spring B 1
22 F4-03.05.02.01 adjustable bracket for angle 1
23 F4-03.05.02.03 torsion spring A 1
24 F4-03.05.02.02 rubber coating,bracket handle 1
25 F4-05.08 bushing,damper circle 2
26 F4-05.09 damper circle 2
27 F4-03.05.05.00 locking circle component 1
28 M4*9 rivets for brake and clutch lining 1
29 F4-03.05.06.01 locking handle 1
30 F4-03.05.06.02 locking screw stern 1
31 M8*30 hexagonal bolt M8*30 2
32 GB848 M8 gasket 8 2
33 F4-04.02 location pin 1
34 M4*20 semi-hollow rivet 4*20 2
35
15F-03.05.02.04
clamp handle 2
36 F4-03.01.03 clamp screw stem,transom 2
37
15F-03.05.02.03
clamp disk 2
