Hidea F 4 HS Каталог запчастей онлайн [7/9] 201615

Hidea F 4 HS Каталог запчастей онлайн [7/9] 201615

REF NO

PART CODE DESCRIPTION（

（（

（EN）

））

）

Q'TY

1 M8*25 hexagonal head bolt M8×25 1

2 F4-04.03 bingder plate,steering handle 1

3 F4-04.04 impair friction circle A 1

4 F4-04.05 gasket A 1

5

F4-04.01.02.00

shock ring component

handle

1

6 F4-04.01.01 steering handle bracket 1

7 F4-04.07 Gasket B 2

8 F4-04.08 gasket,wave shape 1

9 F4-04.06 impair abrasion circle B 1

10 F4-04.09.01 steering hanlde 1

11

GB818 M5*25

cross recessed raised

countersunk screw M5×25

1

12 15F-04.07.14 handle rubber coating 1

13 15F-04.07.13 handle 1

14 M4*20 rivets for name plate 2×5 1

15 短轴(S) rating plate,throttle 1

16 GB848 M10 gasket 10 1

17 15F-04.07.11 spring 1

18 15F-04.07.12 bush 1

19 15F-04.07.09 adjustment knob,resistance 1

20 15F-04.07.08 lock block 1

21

GB818 M5*12

screw,cross pan head

M5×12

2

22 15F-04.07.07 binder plate 1

23 15F-04.07.05 throttle lever 1

24 F4-04.10 cable,throttle control 1
