Selva NAXOS 15 [5/37] Technical features

TECHNICAL FEATURES

MODEL IZMIR 5XS – 170A IZMIR 6XS – 170A NAXOS 6XS – 259A NAXOS 8XS – 259A

POWER 5HP/3,7 Kw 6 HP/4,41 Kw 6 HP/4,41 Kw 8 HP/5,9 Kw

FULL-THROTTLE OP.RAN.(RPM) 4500/5000 4500/5000 4000/4500 4000/4500

DISPLACEMENT (cc.) 170 170 259 259

BORExSTROKE 49x45 49x45 58x49 58x49

NUMBERS OF CYLINDER 2 cyl.in line

ENGINE TYPE Otto cycle-2 stroke

FUEL PUMP No. 1 diaphragm pump

CARBURETTOR FHE 26/20 FHE 26/20 FHE 26/20 FHE 26/20

AVERAGE CONSUMPTION 2,5 l/h 2,5 l/h 3 l/h 4,5 l/h

FUEL Regular gasoline mixed with 2 stroke outboard oil “SELVA OUTBOARD MOTOR OIL” (TC-WII)

FUEL TANK l. 12 l. 12 l. 12 l. 23

ENGINE LUBRIFICATION Gasoline mixed with 2% of 2 stroke outboard oil “SELVA OUTBOARD MOTOR OIL” (TC-WII)

IGNITION Marine, electronic, capacitive discharge

SPARK ADVANCE Electronic, automatic, programmed on engine revolutions

MANUAL STARTING Rope with auto rewind on pulley (1)

ELECTIC STARTING Standard with 12V/70W generator and rectifier for battery recharge

SPARK PLUGS BOSCH W7B-CHAMPION L 87 Y-LODGE H

EXHAUST Underwater, vacuum through boss

COOLING Forced water circulation by pump

GEAR RATIO 13/25

SHIFT CONTROL Forward - Neutral - Reverse

GEARCASE OIL “SELVA OUTBOARD MOTOR GEARBOX OIL” (API GL-5 SAE 80 W/90)

GEARCASE OIL QUANTITY 150 cc. / 140 gr.

PROPELLER TYPE Weedless 3 blades with rubber bushing

TRIM METHOD 5 changeable positions with pin

SUSPENSIONS Vibration dampers

SHAFT LENGHT (mm) Standard shaft 555 - long shaft 685

TRANSOM HEIGHT (mm.) Standard shaft 390 - long shaft 520

WEIGHT (Kg.) Standard shaft Kg. 30 - Long shaft kg 31 Standard shaft Kg. 30,5 - Long shaft kg 31,5

(1) On request 12V/70W current generator and rectifier on polarized current tap

Selva SpA reserves the right to make changes at any time, without notice, in weights, materials, construction, and features without

incurring any obbligation to equip same on models manufactured prior to date of such change
