USING THE PANEL HEATER
1) Description of the control unit:
Switch (stop/0). Temperature adjustment control knob. V1 Heating indicator light
2) Fixing the comfort temperature
The comfort temperature is the temperature that you would like while the room is occupied.
a) Set the switch
on
b) Set the control knob between 17°C and 20°C, the heating indicator V1 comes on if the room temperature is
below the required temperature.
c) Wait a few hours for the temperature to stabilise.
d) If the setting is satisfactory (if necessary use a thermometer to check), mark the position for future use.
e) If the setting is not satisfactory, adjust it and start again from point c).
3) Fixing the Eco temperature:
This is the required temperature during periods when the room is unoccupied. It is recommended that this
mode should be used if the room is unoccupied for more than 2 hours.
a) Set the switch
to .
b) Adjust the control knob
between 17°C and 20°C, The ECO temperature is 3, 5°C under the indicated
temperature on the control knob .
The heating light V1 comes on, if the ambient temperature is lower than the instruction of desired Eco
temperature.
c) Wait a few hours until the temperature stabilizes.
d) If the setting is satisfactory (if necessary use a thermometer to check), mark the position.
If the setting is not satisfactory, adjust it and start again from point c.
4) Frost-Free mode
This mode is used to keep the temperature at approximately 7°C in the room when you are absent from the
house for a prolonged period (i.e. more than 24 hours).
a) Set the switch on
5) The heating indicator: V1
This light comes on when the heating element is working. It may fl ash when the temperature has stabilised.
6) Locking the controls:
It is possible to lock or limit use of the control knob and lock the switch to prevent unauthorised
manipulation of the panel heater (children, etc.).
a) Unhook the panel heater from its wall mounting.
b) Remove the slugs P on the back of the thermostat from their mountings.
c) Select position B to lock the control knob or position L to limit the amount it can be turned. Position M
blocks the switch
7) Programming (Energy save)
The product with electronic thermostat can receive the following signals from a master unit:
- comfort (temperature of (control knob)
- Eco (comfort temperature -3°C to -4°C)
The product must be equipped with mains borne signalling system ex: Chronopass Interface and programming
card.
RECOMMENDATIONS FOR USE
- There is no point in setting maximum heating; the room temperature will not rise any quicker.
- When you air the room, disconnect the panel heater by putting the switch on STOP
- If you leave for several hours, remember to reduce the temperature.
Absence for:
a) Less than 2 hours, do not touch the controls.
b) 2 to 24 hours set the switch in Eco mode
c) More than 24 hours or in the summer, put the switch on
- If you have several units in a room, let them operate simultaneously. This will give you a more uniform
temperature without increasing electricity consumption.
USING THE PANEL WARNINGSHEATER
This device is not intended for use by persons (including children) with
physical, sensory or mental disability, or by persons lacking experience
or knowledge, unless they have received from a person in charge of their
safety adequate supervision or preliminary instructions on how to use the
device. Care must be taken at all times to keep children from playing with the
device. Do not introduce objects or paper into the device. Do not totally or
partially block the grilles on the front or inside of the appliance as this may
cause overheating. If the supply cord is damaged, it must be replaced by a
service agent or similarly qualified person in order to avoid a hazard (applies
to all units). All work to the inside of the appliance must be carried out by a
licensed electrician.
MAINTENANCE
To maintain performances of your unit, you should clean the upper and lower grilles of the unit about twice a
year using a vacuum cleaner or a brush.
Have a professional check the inside of the unit every five years. Dirt may collect on the grille of the unit if
the atmosphere is polluted. This phenomenon is due to the poor quality of the ambient air. In this case, it is
recommended to check that the room is well ventilated (ventilation, air inlet, etc.), and that the air is clean. The
unit will not be replaced under the guarantee because of this type of dirt.
The unit casing should be cleaned with a damp cloth, never use abrasive products. FOR USE
TROUBLE-SHOOTING
If the unit does not heat:
Make sure that the installation circuit breakers are switched on, or that the load shedder (if you have one) has
not switched off the unit power supply. Check the air temperature in the room.
For the model with programmer .Check that the programmer is in COMFORT mode
The unit does not carry out programming orders (Equipped with mains borne signalling system)
Make sure that the programming unit is being correctly used (refer to its user’s manual) or that the Chronocarte
is properly inserted in its housing and that it is operating normally (battery?).
The unit is permanently heating:
Make sure that it is not in a draft and that the temperature setting has not been changed.
This unit with electronic control is equipped with a microprocessor that can be distributed by some severe
mains voltage disturbances (outside EC standards defining the disturbance protection level). If there are any
problems (thermostat blocked, etc.) switch off the unit power supply (fuse, circuit breaker, etc.) for about 5
minutes to allow the unit to start again.
Have your energy distributor check your powers supply if the phenomenon occurs frequently.
431623L_dantex.indd 7 08/06/10 09:42
