Interior View

1. Ribbon supply spindle

2. Label roll guard

3. Label supply spindle

4. Ribbon rewind spindle

5. Sensor switch

6. Print head release lever

7. Front panel

8. Printer cover

9. Print head

10. Platen roller

11. Media sensor

12. Adjustable label guide
