Thomson T42E53DHU [4/31] Buttons on the tv

Introduction

Sockets

Note: The location and names of the sockets on the TV may vary according to

TV model, and not all sockets available on all models.

1. CH+/- (CHANNEL UP/DOWN) button

Scans up/down through the channel list. In the menu system, they act like the up/down direction buttons on the

remote and adjust menu controls.

. MENU ( ) button

Brings up the main menu or press to return to the previous menu.

. VOL+/- (VOLUME UP/DOWN) button

Increases/decreases the volume. In the menu system, they act like the right/left direction buttons on the

remote and adjust menu controls (Note: In some menus, VOLUME UP also acts like the OK button on the remote.)

5. POWER ( )button (Note: For some models, the POWER button is not available.)

Turns the TV on or standby.

Buttons on the TV

Note: The location and names of the function buttons and power button on the TV may vary according to TV model.

and not all buttons available on all models.

SOURCE ( ) button

Press to select signal source.

HDMI socket (input)

HDMI IN

The HDMI can be used to connect a

PC with a compatible video card installed, certain DVD players or a high-definition

compatible digital satellite decoder. This socket p

(High-Definition Multimedia Interface) socket

rovides an uncompressed digital

connection that carries both video and audio data by way of an integrated mini-plug

cable.

AV 1 RCA audio + video sockets (input)

AUDIO

VIDEO

AV 1 IN

The AV 1 IN sockets can be used to connect a range of equipment, including video

recorders, camcorders, decoders, satellite receivers, DVD players, or games

consoles. The VIDEO IN socket provides composite video connection.

USB socket (input)

USB

The socket can be used to connect an USB device.

Note: The number of USB sockets on the TV may vary according to TV model.

SPDIF

SPDIF socket (output)

The SPDIF socket can be used to connect a compatible digital audio receiver.
