– 4 –
E
Please read all the following information,
which contains important instructions for the
safety, the use and the maintenance of the
appliance.
This appliance complies with the following EC
Directives: -73/23/EEC, 93/68/EEC-Low
Voltage Directive-89/336EEC -EMC Directive.
 Never allow children to use the appliance
unsupervised.
 Do not use the appliance If the supply
cord is damaged or faulty.
 If the mains lead is damaged, it must be
replaced by an approved LG Electronics
Service Agent in order to avoid a hazard.
 Always switch the vaccum cleaner off
before :
• changing the dust bag.
• changing or cleaning the filters.

If no dustbag is inserted, the cover cannot
be closed. Please do not use force!
 Do not vacuum flammable or explosive
substances(liquids or gases).
 Do not vacuum hot ash, embers etc. nor
sharp objects.
 Do not vacuum water or other liquids.
Connecting the flexible hose
Push the end of the head(1) on the flexible
hose(2) into the attachment point on the
vacuum cleaner.
To remove the flexible hose from the
vacuum cleaner, press on the button(3) situ-
ated on the head, then pull upwards.
Assembling the tubes
(depending on model)
• Metal tube(4)
- Fit together the two tubes by twisting
slightly.
•Telescopic tube(5)
- Push spring latch(6) forward.
- Pull out tube to required length.
- Release spring latch to lock.
Using the cleaning head and Accessory
Nozzles
(depending on model)
Fit the large cleaning head onto the end of
the tube.
•
The 2 position head(7) is equipped with a
pedal or two pedals(8) which allows you to
alter its position according to the type of
floor to be cleaned.
Hard floor position(tiles, parquet
floors...). Press on the pedal to lower the
brush.
Carpet or rug position. Press on the
pedal to lift the brush up.
•
Crevice Tool(9)
For vacuuming in those normally inaccess-
ible places i.e. reaching cobwebs, or down
the side of a sofa!
How to plug in and use
Pull out the supply cord to the desired
length and plug into the socket.
Press button (13) to start the vacuum cleaner.
To stop it press the button (13) again.
Adjusting the power level
• If your appliance is equipped with an elec-
tronic variable power control(13), you can
choose the power appropriated for the
task.
(depending on model)
•
The flexible hose handle(14) has a manual
air flow regulator(15) which allows you to
briefly reduce the suction level.
Storage(16)
When you have switched off and unplugged
the appliance, press on the button (12) to
automatically rewind the cord.
You can move or store your appliance in a
vertical position by sliding the hook on the
large cleaning head into the clip on the
underside of the appliance.
Information for your safety
How to Use
