EN-44
[Av] Aperture Priority Mode
In this mode, images are captured with the priority given to aperture. The shutter speed is automatically
set according to the aperture. The aperture will affect the depth-of-field of the camera.
If you set a small aperture (higher F value), you can capture portrait images with an out-of-focus
background. Alternatively, if you set a large aperture (lower F value), both close objects and distant
objects will be in focus, for example when capturing landscape images.
1. Slide the mode switch to [ ] and set the mode dial to [Av].
2. Adjust the aperture with the S / T buttons.
J Press the S button to increase the value.
J Press the T button to decrease the value.
J The setting range of the aperture value is as follows:
F6.7, F5.6, F4.8, F4.0, F3.5, F2.8 (Wide).
F4.8, F5.6, F6.7, F8.0, F9.5, F11.0 (Tele).
J The aperture value and corresponding shutter speed are
displayed on the screen. If an appropriate combination cannot
be set, the shutter speed is displayed in red, but images can
be captured regardless.
3. Compose the image, press the shutter button down halfway,
and then press it down fully.
J The aperture value varies depending on the position of the zoom lens.
EN-44
[Av] Aperture Priority Mode
In this mode, images are captured with the priority given to aperture. The shutter speed is automatically
set according to the aperture. The aperture will affect the depth-of-field of the camera.
If you set a small aperture (higher F value), you can capture portrait images with an out-of-focus
background. Alternatively, if you set a large aperture (lower F value), both close objects and distant
objects will be in focus, for example when capturing landscape images.
1. Slide the mode switch to [ ] and set the mode dial to [Av].
2. Adjust the aperture with the S / T buttons.
J Press the S button to increase the value.
J Press the T button to decrease the value.
J The setting range of the aperture value is as follows:
F6.7, F5.6, F4.8, F4.0, F3.5, F2.8 (Wide).
F4.8, F5.6, F6.7, F8.0, F9.5, F11.0 (Tele).
J The aperture value and corresponding shutter speed are
displayed on the screen. If an appropriate combination cannot
be set, the shutter speed is displayed in red, but images can
be captured regardless.
3. Compose the image, press the shutter button down halfway,
and then press it down fully.
J The aperture value varies depending on the position of the zoom lens.
[Àv] Ôîòîðåæèì ïðèîðèòåòà äèàôðàãìû
 ýòîì ðåæèìå ñúåìêà ïðîèñõîäèò ñ ïðèîðèòåòîì äèàôãðàãìû. Âûäåðæêà
àâòîìàòè÷åñêè óñòàíàâëèâàåòñÿ ñîîòâåòñòâåííî çíà÷åíèþ äèàôðàãìû. Äèàôðàãìà
âëèÿåò íà ãëóáèíó ðåçêîñòè ñíèìêîâ.
Åñëè Âû óñòàíàâëèâàåòå ìàëåíüêóþ äèàôãðàãìó (âûøå F çíà÷åíèÿ), Âû ñìîæåò
ïîëó÷èòü èçîáðàæåíèÿ ñ ðîçôîêóñèðîâàííûì ôîíîì. Ñîîòâåòñòâåííî, åñëè Âû
óñòàíàâëèâàåòå áîëüøóþ äèàôãðàãìó (íèçêîå F çíà÷åíèå), êàê áëèçêèå, òàê è
îòäàëåííûå îáúåêòû, áóäóò íàõîäèòüñÿ â ôîêóñå. Íàïðèìåð, êîãäà íåîáõîäèìî ñíÿòü
ëàíäøàôò.
1. Óñòàíîâèòå ïåðåêëþ÷àòåëü ðåæèìîâ è øêàëó ðåæèìîâ â ïîëîæåíèå [Àv]
2. Óñòàíîâèòå çíà÷åíå äèàôãðàãìû êíîïêàìè
Êîìïîíóéòå èçîáðàæåíèÿ, íàæèìàéòå êíîïêó ñïóñêà.
Íàæìèòå ÷òîáû óâåëè÷èòü çíà÷åíèå äèàôãðàãìû.
Íàæìèòå ÷òîáû óìåíüøèòü çíà÷åíèå äèàôãðàãìû.
Äèàïàçîí çíà÷åíèé ïàðàìåòðîâ äèàôãðàãìû òàêîé:
F6.7, F5.6, F4.8, F4.0, F3.5, F2.8. (Øèðîêîôîðìàòíûé)
F4.8, F5.6, F6.7, F8.0, F9.5, F11.0. (Òåëå)
Äèàôðàãìà è ñîîòâåòñòâóþùèå çíà÷åíèÿ âûäåðæêè îòîáðàæàþòñÿ íà
ýêðàíå. Åñëè ñîîòâåòñòâóþùàÿ êîìáèíàöèÿ íå ìîæåò áûòü óñòàíîâëåííîé,
çíà÷åíèÿ âûäåðæêè îòîáðàæàþòñÿ êðàñíûì öâåòîì, íî ñíèìêè ìîãóò áûòü
ïîëó÷åíû íå îáðàùàÿ íà ýòî âíèìàíèÿ.
3. Êîìïîíóéòå èçîáðàæåíèÿ, íàæèìàéòå êíîïêó ñïóñêà ÷àñòè÷íî à ïîòîì
ïîëíîñòüþ.
•
•
•
•
•
EN-43
[Tv] Shutter Speed Priority Photography Mode
In this mode, images are captured with the priority given to shutter speed. The aperture is automatically
set according to the shutter speed. If you set a fast shutter speed, you can capture images of moving
subjects that look as if they are still. If you set a slow shutter speed, you can capture images that give
the impression that the subject is in motion.
1. Slide the mode switch to [ ] and set the mode dial to [Tv].
2. Adjust the shutter speed with the S / T buttons.
J Press the S button to select faster shutter speeds.
J Press the T button to select slower shutter speeds.
J The setting range of the shutter speed is as follows:
1/1500, 1/1250, 1/1000, 1/820, 1/650,1/500, 1/400, 1/320,
1/250, 1/200,1/160, 1/125, 1/100, 1/80, 1/64, 1/50,1/40, 1/32,
1/25, 1/20, 1/16, 1/13, 1/10, 0.13s, 0.16s, 0.2s, 0.25s, 0.3s,
0.4s, 0.5s, 0.6s, 0.8s, 1.0s.
J The shutter speed and corresponding aperture value
ardisplayed on the screen. If an appropriate combination
cannot be set, the aperture value is displayed in red, but
images can be captured regardless.
3. Compose the image, press the shutter button down halfway,
and then press it down fully.
J In the flash photography mode, when [ ] and [ ] are set, the fastest shutter speed is 1/500
second.
EN-43
[Tv] Shutter Speed Priority Photography Mode
In this mode, images are captured with the priority given to shutter speed. The aperture is automatically
set according to the shutter speed. If you set a fast shutter speed, you can capture images of moving
subjects that look as if they are still. If you set a slow shutter speed, you can capture images that give
the impression that the subject is in motion.
1. Slide the mode switch to [ ] and set the mode dial to [Tv].
2. Adjust the shutter speed with the S / T buttons.
J Press the S button to select faster shutter speeds.
J Press the T button to select slower shutter speeds.
J The setting range of the shutter speed is as follows:
1/1500, 1/1250, 1/1000, 1/820, 1/650,1/500, 1/400, 1/320,
1/250, 1/200,1/160, 1/125, 1/100, 1/80, 1/64, 1/50,1/40, 1/32,
1/25, 1/20, 1/16, 1/13, 1/10, 0.13s, 0.16s, 0.2s, 0.25s, 0.3s,
0.4s, 0.5s, 0.6s, 0.8s, 1.0s.
J The shutter speed and corresponding aperture value
ardisplayed on the screen. If an appropriate combination
cannot be set, the aperture value is displayed in red, but
images can be captured regardless.
3. Compose the image, press the shutter button down halfway,
and then press it down fully.
J In the flash photography mode, when [ ] and [ ] are set, the fastest shutter speed is 1/500
second.
EN-43
[Tv] Shutter Speed Priority Photography Mode
In this mode, images are captured with the priority given to shutter speed. The aperture is automatically
set according to the shutter speed. If you set a fast shutter speed, you can capture images of moving
subjects that look as if they are still. If you set a slow shutter speed, you can capture images that give
the impression that the subject is in motion.
1. Slide the mode switch to [ ] and set the mode dial to [Tv].
2. Adjust the shutter speed with the S / T buttons.
J Press the S button to select faster shutter speeds.
J Press the T button to select slower shutter speeds.
J The setting range of the shutter speed is as follows:
1/1500, 1/1250, 1/1000, 1/820, 1/650,1/500, 1/400, 1/320,
1/250, 1/200,1/160, 1/125, 1/100, 1/80, 1/64, 1/50,1/40, 1/32,
1/25, 1/20, 1/16, 1/13, 1/10, 0.13s, 0.16s, 0.2s, 0.25s, 0.3s,
0.4s, 0.5s, 0.6s, 0.8s, 1.0s.
J The shutter speed and corresponding aperture value
ardisplayed on the screen. If an appropriate combination
cannot be set, the aperture value is displayed in red, but
images can be captured regardless.
3. Compose the image, press the shutter button down halfway,
and then press it down fully.
J In the flash photography mode, when [ ] and [ ] are set, the fastest shutter speed is 1/500
second.
EN-45
[M] Manual Mode
In manual mode, the aperture value and the shutter speed can be varied individually.
1. Slide the mode switch to [ ] and set the mode dial to [M].
2. Toggle the button to select the shutter speed or aperture.
3. Adjust the shutter speed or aperture with the S / T buttons.
4. Compose the image, press the shutter button down halfway,
and then press it down fully.
J In the flash photography mode, when [ ] and [ ] are set, the fastest shutter speed is 1/500
second.
Ïðèìå÷àíèå
Çíà÷åíèå äèàôðàãìû çàâèñèò îò ïîëîæåíèÿ îáúåêòèâà
