8
Designs and specifications are subject to change without notice.
Troubleshooting
Correction
RADIO
The function switch is not
set to the Radio mode.
There are electronic
devices near the player.
Set the switch to the Radio
mode.
Set the player far from the
devices.
No power
No sound
Some noise
occurs.
Symptom
Cause
The power cord is not
plugged in.
The batteries are not
remaining.
Plug in the power cord.
Change the batteries with a
new one.
CD
POWER
An unplayable disc is
inserted.
The disc is placed upside
down.
The disc is not placed
within the guide.
The disc is dirty.
Insert a playable disc.
Place the disc with the
playback side down.
Place the disc on the disc
tray correctly inside the
guide.
Clean the disc.
The unit does
not start
playback
TAPE
Record protect tabs are
removed.
Cover holes on back edge
of tape with tap
.
Unable to
record
General
Power supply Refer to the main label
Power consumption Refer to the main label
Net Weight 2.1 kg
External dimensions (W x H x D) (333 x 178 x 259) mm
Operating temperature 5
o
C to 35
o
C
Operating humidity 5 % to 85 %
Tuner
FM Tuning Range 88 to 108 MHz or 65 to 108 MHz
AM Tuning Range 520 to 1610 kHz or 520 to 1710 kHz
CD
Frequency response 100 Hz to 18 kHz
Signal-to-noise ratio 55 dB
Dynamic range 55 dB
Amplifier
Output Power 0.5 W x 2 ch
T.H.D 10 %
Frequency Response 120 Hz to 18 kHz
Signal-to-noise ratio 50 dB
Speakers
Type 2 Way 2 Speaker
Impedance 8 Ω
Rated Input Power 0.5 W
Max. Input Power 1.0 W
USB
Version 1.1
Bus Power supply DC 5 V 500 mA
Specifications
Notice (the date of the production of goods).
First figure ( of the left ) of series number means Year,
next 2 figures - Month of the production of this goods.
LPC14-ACISLL-ENG 2/4/10 10:49 AM Page 8
