ASRock AB350M-HDV [7/66] English
![ASRock AB350M-HDV [7/66] English](/views2/1253648/page7/bg7.png)
English
2
1.2 Specications
Platform
•
Micro ATX Form Factor
•
Solid Capacitor design
CPU
•
Supports AMD Socket AM4 A-Series APUs (Bristol Ridge)
and Ryzen Series CPUs (Summit Ridge)
•
Digi Power design
•
7 Power Phase design
•
Supports CPU up to 65W
Chipset
•
AMD Promontory B350 (AB350M-HDV)
•
AMD Promontory A320 (A320M-HDV/A320M-DGS)
Memory
•
Dual Channel DDR4 Memory Technology
•
2 x DDR4 DIMM Slots
•
Supports DDR4 2667/2400/2133 ECC & non-ECC, un-bu-
ered memory*
* Please refer to page 23 for DDR4 UDIMM maximum
frequency support.
•
Max. capacity of system memory: 32GB
•
15μ Gold Contact in DIMM Slots
Expansion
Slot
•
1 x PCI Express 3.0 x16 Slot (PCIE2 @ x16 mode)*
* Supports NVMe SSD as boot disks
* PCIE2 will downgrade to x8 mode when A-Series APU is
installed.
•
1 x PCI Express 2.0 x1 Slot
Graphics
•
Integrated AMD Radeon
TM
R7 Series Graphics in A-series /
E-series APU
•
DirectX 12, Pixel Shader 5.0
•
Max. shared memory 2GB
AB350M-HDV/A320M-HDV:
•
ree graphics output options: D-Sub, DVI-D and HDMI
•
Supports Triple Monitor
•
Supports HDMI with max. resolution up to 4K x 2K
(4096x2160) @ 24Hz / (3840x2160) @ 30Hz
•
Supports DVI-D with max. resolution up to 1920x1200 @
60Hz
