ASRock J3455M [11/51] English
![ASRock J3455M [11/51] English](/views2/1253663/page11/bgb.png)
6
English
No. Description
1 BIOS_PH Connector
2 CPU Fan Connector (CPU_FAN1)
3 Clear CMOS Jumper (CLRMOS1)
4 2 x 240-pin DDR3 DIMM Slots (DDR3_A1, DDR3_B1)
5 ATX Power Connector (ATXPWR1)
6 SATA3 Connector (SATA3_1)
7 SATA3 Connector (SATA3_2)
8 USB 3.0 Header (USB3_2_3)
9 Chassis Intrusion and Speaker Header (SPK_CI1)
10 System Panel Header (PANEL1)
11 Chassis Fan Connector (CHA_FAN1)
12 USB 2.0 Header (USB_4_5)
13 USB 2.0 Header (USB6)
14 USB 2.0 Header (USB_2_3)
15 Print Port Header (LPT1)
16 COM Port Header (COM1)
17 COM Port Header (COM2)
18 TPM Header (TPMS1)
19 Front Panel Audio Header (HD_AUDIO1)
