English
6
•
3 x USB 2.0 Headers (Support 6 USB 2.0 ports) (Intel® Z270)
(Supports ESD Protection (ASRock Full Spike Protection))
•
1 x USB 3.0 Header (Supports 2 USB 3.0 ports) (Intel® Z270)
(Supports ESD Protection (ASRock Full Spike Protection))
•
1 x USB 3.0 Header (Supports 2 USB 3.0 ports) (ASMedia
ASM1074 hub) (Supports ESD Protection (ASRock Full Spike
Protection))
BIOS
Feature
•
2 x AMI UEFI Legal BIOS with multilingual GUI support (1
x Main BIOS and 1 x Backup BIOS)
•
Supports Secure Backup UEFI Technology
•
ACPI 6.0 Compliant wake up events
•
SMBIOS 2.7 Support
•
CPU, GT_CPU, DRAM, VPP, PCH 1.0V, VCCIO, VCCST,
VCCSA, VCCPLL Voltage Multi-adjustment
Hardware
Monitor
•
CPU / Chassis / CPU Optional/Water Pump / Chassis
Optional/Water Pump temperature sensing
•
CPU / Chassis / CPU Optional/Water Pump / Chassis
Optional/Water Pump Fan Tachometer
•
CPU / Chassis / CPU Optional/Water Pump / Chassis Op-
tional/Water Pump Quiet Fan (Auto adjust chassis fan speed
by CPU temperature)
•
CPU / Chassis / CPU Optional/Water Pump / Chassis Op-
tional/Water Pump Fan multi-speed control
•
Voltage monitoring: +12V, +5V, +3.3V, CPU Vcore, DRAM,
VPP, PCH 1.0V, VCCSA, VCCST
OS
•
Microso® Windows® 10 64-bit (For 7
th
Gen Intel® CPU)
•
Microso® Windows® 10 64-bit / 8.1 64-bit / 7 32-bit / 7 64-
bit (For 6
th
Gen Intel® CPU)
* To install Windows® 7 OS, a modied installation disk with
xHCI drivers packed into the ISO le is required. Please refer to
page 49 for more detailed instructions.
* For the updated Windows® 10 driver, please visit ASRock’s
website for details: http://www.asrock.com
Certica-
tions
•
FCC, CE, WHQL, RCM, BSMI
•
ErP/EuP ready (ErP/EuP ready power supply is required)
