Activity/Link LED Speed LED

Status Description Status Description

Off Nolink OFF 10Mbpsconnection

Orange Linked ORANGE 100Mbpsconnection

Orange(Blinking) Dataactivity GREEN 1Gbpsconnection

Orange(Blinking

thensteady)

ReadytowakeupfromS5

mode

4. Line In port (light blue).Thisportconnectstothetape,CD,DVDplayer,orother

audiosources.

5. Line Out port (lime).Thisportconnectstoaheadphoneoraspeaker.Inthe4.1,5.1

and7.1-channelcongurations,thefunctionofthisportbecomesFrontSpeakerOut.

6. Microphone port (pink).Thisportconnectstoamicrophone.

Refertotheaudiocongurationtableforthefunctionoftheaudioportsin2.1,4.1,5.1,or

7.1-channelconguration.

Rear panel connectors

4 53

6710

9 8

1. PS/2 Mouse port (green).ThisportisforaPS/2mouse.

2. Parallel port.This25-pinportconnectsaparallelprinter,a

scanner,orotherdevices.

3. LAN (RJ-45) port.ThisportallowsGigabitconnectiontoa

LocalAreaNetwork(LAN)throughanetworkhub.Refertothe

tablebelowfortheLANportLEDindications.

LAN port LED indications

LAN port

Speed

LED

Activity Link

LED
