Hyundai H-AR7-09H-UI135 [8/68] Remote control

Electric air conditioner (split system)

The remote control serves as a remote thermostat allowing for the precise temperature control

at its location.

Improving the quality of indoor air is one of the mission of an air conditioner. This air conditioner

is equipped with ionizer or Plasma Dust Collector (depending on specic conguration of the

model).

With the anions generated by Ionizer, the air circulation of the air conditioner lls the room with

refreshing, natural and healthy air. The Plasma Dust Collector generates an high voltage ioniza-

tion zone, through which the air is converted to plasma. Inside the air most of the dust, moke,

and pollen particles are captured by the electrostatic lter.

Anti-mildew function(optioal)

When turns o the unit on COOL, DRY, AUTO (Cool) mode, the air conditioner will continue oper-

ating for about 7-10 minutes (depending on models) at LOW fan speed.

This will help to dry up the condensed water inside the evaporator, and prevent the breeding of

mildew.

Under Anti-mildew operation, do not restart the air conditioner until the unit is completely o.

REMOTE CONTROL

1. ON/OFF Button. Operation starts when this button is pressed and stops when this button is

pressed again.

2. MODE Button. Each time the button is pressed, the operationmode is selected in a sequence

of following:

3. SPEED BUTTON. Used to select the fan speed in four steps:

4. SLEEP BUTTON.

• Active/Disable sleep function. It can maintain the most comfortable temperature and save

energy. This function is available on COOL, HEAT or AUTO mode only.

• For the detail, see sleep operation in USER S MANUAL

5. ION BUTTON. Active/Disable ION function. When the ION function is initiated, the Ionizer/

Plasma. Dust Collector (depending on models) is energized and will help to remove pollen and

impurities from the air.

Fig. 3

speed

temp

mode

memory

timer on

swing directionsleep

timer oﬀ

cleanmaxi climate control
