13.

Electric air conditioner (split system)

1. DIGITAL DISPLAY area:

This area will show the set temperature and, if in the TIMER mode, will show the ON and OFF set-

tings of the TIMER. If in the FAN mode, nothing is appeared.

2. TRANSMISSION Indicator:

This indicator ashes one time when remote controller transmits signals to the indoor unit.

3. ON/OFF Indicator:

This symbol appears when the unit is turned on by the remote controller, and disappear when the

unit is turned o.

4. OPERATION MODE Indicator:

When press the MODE button, it shows the current operating mode -- “AUTO”, “COOL”,”DRY”,

“HEAT”(Cooling only model without) ,or “FAN” mode.

5. LOCK Indicator:

LOCK display is displayed by pushing the LOCK button. Push the LOCK button to clear display.

6. TIMER DISPLAY Indicator:

This display area shows the settings of the TIMER. That is, if only the starting time of operation is set,

it will display the TIMER ON. If only the turning o time of operation is set, it will display the TIMER

OFF. If both operations are set, it will show TIMER ON-OFF which indicates you have chosen to set

both the starting time and o time.

7. FAN SPEED Indicator:

Press the FAN SPEED button to select the desired fan speed setting (Auto-Low-Med-High). You

selection will be displayed in the LCD window except the Auto fan speed.

Operating the Remote Controller

Install/Replace Batteries

The Remote Controller uses two dry batteries(LR03X2).

1. To install the batteries, slide the back cover of the battery compartment and install the batter-

ies according the direction (+and -)shown on the Remote Controller.

2. To replace the old batteries, use the same method as mentioned above.

AUTOMATIC OPERATION

1. Use the MODE button to select AUTO.

2. Push the TEMP button to set the desired room temperature .

The most comfortable temperature settings are between 21 C to 28 C.

3. Push the ON/OFF button to start the air conditioner. The OPERATION

lamp on the display panel of the indoor unit lights. The

FAN SPEED is automatically set and there are no fan speed

indicators shown on the display panel of the remote controller.

4. Push the ON/OFF button again to stop the unit operation.

NOTE

1. In the AUTO mode, the air conditioner can logically choose

the mode of COOL, FAN and HEAT by sensing the dierence

between the actual ambient room temperature and the set

temperature on the remote controller.

2. If the AUTO mode is not comfortable for you, the desired

mode can be selected manually.

COOL/ HEAT and FAN Operation

1. If the AUTO mode is not comfortable, you may manually over-ride

the settings by using COOL, HEAT or FAN modes.

2. Push the TEMP button to set the desired room temperature. Ў When in COOLING mode, the

most comfortable settings are 21C

or above. When in HEATING mode, the most comfortable Ў settings are 28C or b elow.

3. Push the FAN SPEED to select the FAN mode of AUTO, HIGH,

MED or LOW.

4. Push the ON/OFF button, the operation lamp lights and the air

conditioner start to operate as your settings. Push the ON/OFF

button again to stop this unit operation.
