USB Chipset+ASMedia
®
USB 3.1 Gen 2 Controller:
- 1 x USB Type-C
™
port on the back panel, with USB 3.1 Gen 2 support
- 1xUSB3.1Gen2Type-Aport(red)onthebackpanel
Chipset:
- 8 x USB 3.1 Gen 1 ports (4 ports on the back panel, 4 ports available through
theinternalUSBheaders)
- 6 x USB 2.0/1.1 ports (2 ports on the back panel, 4 ports available through
theinternalUSBheaders)
Internal
Connectors
1 x 24-pin ATX main power connector
1 x 8-pin ATX 12V power connector
2 x M.2 Socket 3 connectors
6 x SATA 6Gb/s connectors
1 x CPU fan header
1 x water cooling CPU fan header
2 x system fan headers
1 x system fan/water cooling pump header
2xdigitalLEDstripheaders
2xdigitalLEDstrippowerselectjumpers
2xRGB(RGBW)LEDstripheaders
1 x front panel header
1 x front panel audio header
2 x USB 3.1 Gen 1 headers
2 x USB 2.0/1.1 headers
1xS/PDIFOutheader
1xTrusted Platform Module (TPM)header(2x6 pin, for the GC-TPM2.0_S
moduleonly)
1 x Thunderbolt
™
add-in card connector
1 x Clear CMOS jumper
Back Panel
Connectors
1 x PS/2 keyboard/mouse port
1xDVI-Dport
1xHDMIport
1 x USB Type-C
™
port, with USB 3.1 Gen 2 support
1xUSB3.1Gen2Type-Aport(red)
4 x USB 3.1 Gen 1 ports
2 x USB 2.0/1.1 ports
1 x RJ-45 port
6 x audio jacks (Center/Subwoofer Speaker Out, Rear Speaker Out, Side Speaker
Out,LineIn,LineOut,MicIn)
I/O Controller iTE
®
I/O Controller Chip
Hardware
Monitor
Voltage detection
Temperature detection
Fan speed detection
Watercoolingowratedetection
Overheating warning
Fan fail warning
Fan speed control
* Whetherthefan(pump)speedcontrolfunctionissupportedwilldependonthefan
(pump)youinstall.
- 7 -
