Asus K551LB, 90NB02A2-M03010 [105/138] Replace and secure the back cover with the screws you removed earlier refer below for the proper placement of screws

Notebook PC E-Manual

105

9. Replace and secure the back cover with the screws you removed

earlier. Refer below for the proper placement of screws.

Screws set

Long (L) Medium (M) Short (S)
