H-MS1104 (www.hyundai-electronics.ru) 19
Radio operations
 Please connect FM/AM antenna to the jacks on rear panel.
 Press SOURCE SELECT button on the RC or SOURCE on the front panel until you enter Radio
system, and press TITLE/AM/FM button to choose FM or AM range.
 Manual adjustment. Press CH PREV/NEXT buttons or SEARCH (F.FWD/REW) button to enable
adjustment of radio stations.
 Automatic adjustment. Press and hold SUBTITLE/AUTO button, the tuner will automatically find the
radio stations. After finding the station, the radio frequency will be shown on DVD-player display.
 This unit can memorize 80 radio stations (FM/AM)
 If you want to save radio station in memory, you need to choose the memory item with CH
PREV/NEXT buttons. In manual or automatic mode find the radio station you want to save. Then
press MEMORY/AUDIO button, and after it input the corresponding number to save the station.
 Repeat all above-note functions to memorize other radio stations.
 If you want to listen to a radio station that you have memorized, press CH PREV/NEXT buttons and
choose the necessary channel.
MP3 playback
 MP3 is the third audio compression format of international standard MPEG, which compresses the
audio signal at the rate of 12:1. Using MP3 format, one disc can contain more than 600 minutes of
music, the timbre of which is similar with that of CD discs.
 There are many different formats for storing MP3 songs. Usually, one MP3 disc includes many folders
(directories) and every folder includes files (songs).
 Use the UP/DOWN cursor buttons to select the directory you want and press the ENTER button to
enter. Press the ENTER button to play the file you selected.
Play picture disc
 When picture disc menu appears on the TV screen, press cursor buttons to choose the needed folder,
then press ENTER, PLAY/PAUSE button to enter the selected folder.
 Select the needed file in the folder and press ENTER, PLAY/PAUSE button to playback the file.
 Press STOP button, 12 small pictures will be shown on the TV screen.
 Press UP/DOWN/LEFT/RIGHT cursor buttons to select the desired picture.
 Use UP/DOWN/LEFT/RIGHT cursor buttons to select SLIDE SHOW, then press PLAY/PAUSE
button to start random playing.
 Use UP/DOWN/LEFT/RIGHT cursor buttons to MENU, the press PLAY/PAUSE button to enter
button function menu.
Button function menu
Also you can choose the following functions:
[STOP]: entering picture thumbnail mode;
[PREV]: previous picture;
[NEXT]: next picture;
[PLAY/PAUSE]: to play picture or pause picture;
Select CONTINUE to go to the next menu page.
[ZOOM]: change zoom mode;
[F.FWD]: zoom in picture;
[REW]: zoom out picture;
[LEFT/RIGHT]: move zoom center during zoom in picture.
Select EXIT MENU to exit.
