7 Getting to know your monitor
Getting to know your monitor
Front view
Back view
1. Control buttons
2. Power button
1
2
3. Speakers (for models with speakers)
4. Input and output ports (vary by model,
see Input and output ports on page 8)
5. Kensington lock slot
33
5
4
• Above diagram may vary depending on the model.
• Picture may differ from product supplied for your region.
