TXM SERIES

™

TXM SERIES

™

Product Speciﬁcations

TXM .......................... 

TXM .......................... 

TXM .......................... 

TXM .......................... 

Installation .................. 

SafetyandAgency

Approvals .................... 

Warranty ..................... 

Congratulations on the purchase of your new Corsair

TXM Series High Performance ATX power supply.

Corsair TXM Series enthusiast power supplies are optimized for silence,

with a custom fan design. 80 PLUS Gold rated eciency ensures

low-cost operation, and the modular black cables allow for fast,

neat builds. All Japanese 105°C capacitors make it a great choice for

high performance PCs where reliability is essential.

Safety and protection

• Over-voltage protection (OVP)

Over-voltage protection for the 12V, 5V and 3.3V DC outputs

is required to comply with the ATX speciﬁcation. OVP shuts

down the PSU in the event that the DC outputs exceed

a set level, determined by the PSU manufacturer. The minimum

voltage levels required for compliance are 13.4V for the

+12V rail(s), 5.74V for the +5V rail and 3.76V for the 3.3V rail.

• Over-current protection (OCP)

The TXM Series features OCP on the 3.3V, 5V and 12V rails.

OCP ensures that the output of the DC voltage rails remains

within safe operating limits.

• Over-temperature protection (OTP)

OTP ensures that the PSU will shut down when the internal

temperature reaches a set point. This is usually as a result

of internal current overloading or a fan failure.

• Short-circuit protection (SCP)

A short-circuit is deﬁned as any output impedance of less than 0.1

ohms. Amongst other things, SCP ensures that the PSU shuts down

should the 3.3V, 5V and 12V rails short to any other rail,

or to ground. It also ensures that no damage should occur to

the unit, or your PC’s components in the event of a short.
