Kenwood KDC-WF431A [35/38] Parts list
![Kenwood KDC-W431GY [35/38] Parts list](/views2/1263108/page35/bg23.png)
35
KDC-W4031/W4031Y/W409/W409Y
KDC-W431GY/W4531/W4531Y/WF431A
Indicates safety critical components.
Ref. No.
A
d
d
N
e
w
Parts No. Description
Desti-
nation
Ref. No.
A
d
d
N
e
w
Parts No. Description
Desti-
nation
PARTS LIST
MECHANISM UNIT (X92-4850-00)
E : KDC-W4531 E1 : KDC-W4031 E2 : KDC-W409 E3 : KDC-W431GY E6 : KDC-WF431A
E7 : KDC-W4531Y E8 : KDC-W4031Y E9 : KDC-W409Y
(E : Europe K : North America M : Other Areas W : Without Europe)
D254 AM01ZNF DIODE
E7E8E9
D254
✽
10EDA20 DIODE
EE1E2
D254
✽
10EDA20 DIODE
E7E8E9
D255-258 D1F60-5063 DIODE
EE1E2
D255-258 D1F60-5063 DIODE
E7E8E9
D255-258 1SR154-400 DIODE
EE1E2
D255-258 1SR154-400 DIODE
E7E8E9
D259 1SS133 DIODE E3E6
D259,260 1SS133 DIODE
EE1E2
D259,260 1SS133 DIODE
E7E8E9
D261 1SS355 DIODE
D301-304 MAZ4062-L ZENER DIODE EE7
D305,306 MAZ4068N-M ZENER DIODE EE7
D402,403 DAN202U DIODE
D402,403
✽
KDS121-P DIODE
D402,403
✽
MC2848 DIODE
D501 RN739F DIODE
D502,503
✽
KP2311ETR-G DIODE
D504
✽
KV1430STL-G
VARIABLE CAPACITANCE DIODE
D506
✽
HVC383B-E
VARIABLE CAPACITANCE DIODE
IC1
✽
784225GC256A MICROCONTROLLER IC
IC3
✽
BD4912-V4 ANALOGUE IC
IC4 E-TDA7560A ANALOGUE IC
EE1E2
IC4 E-TDA7560A ANALOGUE IC
E7E8E9
IC4
✽
TB2904HQ ANALOGUE IC E3E6
IC6 TC7W02FU-F MOS-IC
IC7 E-TDA7479AD ANALOGUE IC
EE1E2
IC7 E-TDA7479AD ANALOGUE IC
E6E7E8
IC7 E-TDA7479AD ANALOGUE IC E9
IC8
✽
S-80836CNNB-G MOS-IC
IC10
✽
E-TDA7516 ANALOGUE IC
IC11
✽
BR24L04FV-W ROM IC
IC15
✽
BA00CCWT ANALOGUE IC
Q51-53 2SC4081 TRANSISTOR
Q71 UMC2N TRANSISTOR
Q72 2SB1565(E,F) TRANSISTOR
Q73 2SD1858 TRANSISTOR
Q74 UMC2N TRANSISTOR
Q151 DTA114YUA DIGITAL TRANSISTOR
Q151
✽
KRA307-P DIGITAL TRANSISTOR
Q151 RT1P144M TRANSISTOR
Q155 2SC4081 TRANSISTOR
Q252
✽
KTA2014P(Y,GR) TRANSISTOR
Q252 2SA1576A TRANSISTOR
Q252
✽
2SA1603A TRANSISTOR
Q330 DTA124EUA DIGITAL TRANSISTOR
Q330 KRA303-P DIGITAL TRANSISTOR
Q330 RT1P241M TRANSISTOR
Q351,352 DTC143TUA DIGITAL TRANSISTOR
Q351,352 KRC410-P DIGITAL TRANSISTOR
Q351,352 RT1N430M TRANSISTOR
Q501
✽
HN3G01J(BL)-F TRANSISTOR
TH1 PRF21BE471QB2 POSITIVE RESISTOR
21BA10-4827-32 CHASSIS
51BD10-4576-83 ARM ASSY
82AD10-4579-23 LEVER ASSY
10 2A D10-4581-13 ARM
11 2A D10-4582-13 ARM
12 3A D10-4583-03 ARM
13 3A D10-4584-03 ARM
14 3B D10-4585-03 ARM
15 2A D10-4586-13 SLIDER
16 3B D10-4587-52 SLIDER
17 2B D10-4588-13 SLIDER
18 2B D10-4595-04 ARM
19 2B D10-4596-24 ARM
22 2A D13-2151-04 GEAR
23 2B D13-2152-04 GEAR
24 3B D13-2153-04 GEAR
25 3B D13-2154-04 GEAR
26 3B D13-2155-04 WORM
27 2B D13-2156-14 GEAR
28 3B D13-2157-04 GEAR
29 2B D13-2158-04 GEAR
30 2B D13-2168-04 GEAR
31 3B D13-2171-04 GEAR
32 1B D13-2172-13 RACK (GEAR)
33 2A D14-0759-04 ROLLER
35 2B D21-2382-04 SHAFT
36 1A D23-0954-04 RETAINER
37 1B D39-0246-05 DAMPER
38 2B G01-3072-04 EXTENSION SPRING
39 2A G01-3073-04 TORSION COIL SPRING
40 2A G01-3074-04 EXTENSION SPRING
41 1B G01-3075-14 EXTENSION SPRING
42 2A G01-3076-04 EXTENSION SPRING
43 1B G01-3077-14 EXTENSION SPRING
44 2B G02-1399-04 FLAT SPRING
45 2B G02-1408-04 FLAT SPRING
51 1A J21-9676-32 MOUNTING HARDWARE
52 3B J21-9677-22 MOUNTING HARDWARE
53 1B J21-9678-13 MOUNTING HARDWARE
55 1A J90-1001-11 GUIDE
56 1B J90-1023-03 GUIDE
DFPC1 3A J84-0141-05
FLEXIBLE PRINTED WIRING BOARD
A2BN09-4460-05
TAPTITE SCREW (OVAL P TAPTIT)
B1BN09-4472-15 MACHINE SCREW (M1.7X8.0)
C2BN09-6004-05
MACHINE SCREW (M1.7X2.5 IB-L)
E2BN09-6007-05 MACHINE SCREW (PAN M2X2)
F1AN09-6051-05 TAPTITE SCREW (BIND P 2X5)
G2AN19-2163-04 FLAT WASHER
H1BN39-2020-46 PAN HEAD MACHINE SCREW
J1BN09-6108-05 MACHINE SCREW (M2
✽
3.5)
K3BN09-6155-05
SEMS (TAPTITE SCREW) (PT2X6)
ELECTRIC UNIT (X34-3402-7x)
