D-Link DAP-2230/UPA [10/139] Hardware overview

5D-Link DAP-2230 User Manual

Section 1 - Product Overview

Hardware Overview

Top Panel

Power/Status LED

Static Green Ready/Working Properly

Flashing Green Transmitting/Receiving data

Flashing Red Malfunction during boot

Solid Red Boot failure
