Removing the power-adapter

port

WARNING: Before working inside your computer, read the safety

information that shipped with your computer and follow the steps in

Before working inside your computer. After working inside your

computer, follow the instructions in After working inside your

computer. For more safety best practices, see the Regulatory

Compliance home page at www.dell.com/regulatory_compliance.

Prerequisites

1 Remove the optical drive.

2 Remove the base cover.

3 Remove the I/O board.

4 Remove the hard drive.

5 Remove the battery.

6 Remove the status-light board.

7 Remove the memory modules.

8 Remove the wireless card.

9 Remove the system-board assembly.

10 Remove the heat-sink assembly.

11 Remove the display panel.

Procedure

1 Remove the screw that secures the power-adapter port to the palm rest

and keyboard assembly.

2 Remove the power-adapter port cable from the routing guides on the

palm rest and keyboard assembly.
