Part 2 - Appendix
27
Troubleshooting
Problem Solution
The main unit won't turn on.
● Check the power cable connection status.
● Check the power outlet.
Unable to display Live video.
● Check the camera's video cable connection status.
● Check the monitor's video cable connection status.
● Check the camera's power setting.
● Check the camera lens settings.
NVR stopped working in the
middle of a recording.
● Hard disk may be full. Delete video recordings to free up space.
● Set the NVR to Recycle mode. For more information, refer to the General in
the operation manual.
icon is shown, but video is
not being recorded.
If the Pre-Event is enabled, the and icons appears when recording is not
inprogress, or the
and icons appear when an event occurs and recording
is in progress. For more information, refer to the Schedule in the operation
manual.
The NVR keeps on rebooting
during a system upgrade
without completing the
upgrade.
Check the upgrade le's version. To downgrade to a previous version, you must
rst press the factory reset button and reset all NVR settings to their factory
defaults. A factory reset will clear all NVR settings congured by the user. For
more information on factory reset, refer to the Factory Reset on page 16.
